Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
1
40 Amp
Green
—
Blower Motor
2
40 Amp
Green
—
Anti-Lock Brakes (ABS)
Pump Feed/Starter
3
30 Amp
Pink
—
Body Control Module
(BCM) – Battery Feed
4
20 Amp
Blue
—
Amplifier
5
30 Amp
Pink
—
Ignition Switch Run/
Accessory Feed – Win-
dows
6
40 Amp
Green
—
Body Control Module
(BCM) – Battery Feed
7
30 Amp
Pink
—
Anti-Lock Brakes (ABS)
Module
Cavity Car-
tridge
Fuse
Mini-
Fuse
Description
8
30 Amp
Pink
—
Ignition Switch Run/
Accessory Feed
9
40 Amp
Green
—
Headlights
10
30 Amp
Pink
—
Ignition Switch Run Feed
11
—
20 Amp
Yellow
Auto Shutdown Relay
(ASD)
12
—
20 Amp
Yellow
Cigar Lighter
13
—
15 Amp
Blue
Hazard Flasher
14
—
20 Amp
Yellow
Auto Shutdown Relay
(ASD)
15
—
25 Amp
Clear
Rear Window Defogger
(EBL)
246
MAINTAINING YOUR VEHICLE
