High Resolution Image--Natural resolution of 1365x1024 pixels
provides easy handling of SXGA workstation 1280x1024 graphics and
1000 line TV images. New improved Digital TV display menu and
function for SD (Standard Definition, 480i/480p) and high definition
HDTV sources. Full 720p (progressive) and 1080i (interlocked) HDTV
display options.
Superior Image Quality--High brightness, saturated color and crisp
well defined details are provided by the color balanced Xenon lamp
with extra-high brightness along with 10 bit digital gamma correction
electronics for accurate color shades.
User Friendly--With size and weight below CRT projectors, this unit is
easy to move and install. It has a simple IR remote and easy to read
menu, and can be remotely controlled from a computer via the RS-232
serial port.
Quick and Easy Setup--The "out of box to operation" time is under 2
minutes! The single lens need only be adjusted by the power focus
and zoom control. Inputs are clear and conveniently arranged.
Versatile--There are two computer and three video inputs. Computer
images from VGA (640x480) through SXGA (1280x1024) are
automatically detected and via Adaptive DPC (Digital Pixel Conversion)
displayed in the optimum form. Composite, S-video, component or
high definition video can also be displayed. Normal NTSC is displayed
in enhanced form without visible scan lines. Full resolution of the 1080
interlace or 720 progressive HDTV images.
Audio Visual Products
Dukane Corporation
Audio Visual Products Division
2900 Dukane Drive
St. Charles, IL 60174-3395
Phone: (630) 584-2300
Fax: (630) 584-5156
E-mail: [email protected]
Internet: www.dukane.com
Toll-Free: 1 (800) 676-2485
1 (800) 676-2486
Electronic Features
LCD Type 0.9 inch Diagonal Direct Drive Liquid Crystal
Light Valves (3), D-ILA TM
Colors 16.7 Million, 24 bit
Resolution 1365 x 1024
1000 TV Lines (Video)
Contrast Ratio 3 50:1
Lumens 2000
Projection Distance 8' (2.5m) min. up to 65' (20m) max.
Image Size 3.5' (1.1m) min. diagonal up to
43' (13.2m) max. diagonal
Speakers 2, Stereo, 2 Watts
Computer Compatibility
VGA (640X480), SVGA (800X600), XGA (1024X768), SXGA (1280X1024) MacIntosh
Series w/13", 16", 19", 21" (640x480, 832x624, 1024x768, 1152x870, 1280x1024)
Horizontal Frequency 15-82kHz
Vertical Frequency 50-78 Hz
Video Compatibility
NTSC/PAL/SECAM; S-Video, Composite, Component, HDTV (1080i, 720p),
and W-VHS
Optical
1.5x Projection Lens 1.5x Motorized Zoom and Focus
Keystone Correction Full shift off axis.
Projection Options Both horizontal and vertical reversal for
rear and ceiling mounts.
Lamp
550 Watt Xenon Arc, 1,000 Hours
Sound System
Stereo Built in stereo speakers (1W + 1W stereo)
Interface Connections
Computer Input (1) Analog, D sub 15 pin
Computer Input (2) Analog, RGB
Computer Input Audio, Stereo
Video (1) Input Composite
Video (2) Input S-Video, Y/C separated
Video (3) Input Component, HDTV
Video Input Audio, Stereo
Control RS-232C
Control Jack for IR Remote
Outputs
Computer Monitor (1) D sub 15 pin
Audio Stereo, mini-jack
Controls
Main Unit Operate, Video, Computer, All Settings
Remote Operate, Video, Computer, Volume, Zoom,
Focus, Menu Functions, Quick Align, AV
Muting
Facility System RS-232C, interface for control by a personal
computer or room system.
Power Requirements
Operating Voltage 100-120V, 50/60 Hz, 700 Watt
Dimensions
16 3/4"W x 13 3/8"D X 9 3/8"H (excluding lens)
Weight
Unit Weight: 3
8 lbs. (14.4 kg); Shipping 45 lbs. (21.4 kg)
Regulatory Compliance UL/C-UL
Accessories (Included)
Wireless IR Remote Control with Batteries, Mac Adapters, Lens Cover, PC cable, 5' AV
Cable, 9' PC Audio Cable, BNC-RCA adapter, AC Power Cord
Accessories (Optional)
Male 13W3 to 15 pin VGA connector for workstations #200-1228,
ATA Case (#185-402)
Specifications New: 2000 Lumens Light Output
Projector Features
Specifications (cont.)
Model 28A9020
SXGA Data/Video
LCD Projector
UL
®
UL
®
C
Specifications subject to change without prior notice
Warranty
Five (5) Year Limited Warranty on Parts and Labor in North America;
LAMPS EXCLUDED (for Other Locations, Local Warranties Apply).
Includes Dukane's FREE TWO YEAR Peace-of-Mind Loaner Program.
Extended Peace-of-Mind Available (Continuing Coverage Plan).
5
YEAR
NEW
Form #11504-B-01
