Page 4: Scissor lift dimensions
Scissor Lift by Draper
page 4 of 6
Maximum
Lowering Retracted
Model
Distance
Height
1
SL4
4'
8
1
/
8
"
SL5
5'
9
1
/
8
"
SL6
6'
10
1
/
8
"
SL7
7'
11
1
/
8
"
SL8
8' 12
1
/
8
"
SL9
9'
13
1
/
8
"
SL10
10'
14
1
/
8
"
SLX11
11'
13¾"
SLX12
12'
15¾"
SLX13
13'
15¾"
SLX14
14'
16¾"
SLX15
15'
16¾"
SLX16
16'
18¾"
SLX17
17'
18¾"
1
Low Profi le Mount adds 4
7
/
8
",
including universal projector
bracket, to unit height.
SL Series
SLX Series
Typical Installation Details
Space for projector's
ceiling mounting bracket
Space for projector
Optional ceiling
closure panel
See chart
(shown slightly lowered)
Pair of
3/16
" aircraft cables
Fail-safe inertial
safety belt system
9/16" dia.
mounting holes
27"
24¾"
29½"
26¾"
2"
23"
20¾"
23½"
20¾"
9
/
16
" dia.
mounting holes
See chart
(shown slightly
lowered)
Space for
projector's
ceiling
mounting
bracket
Space for projector
Optional ceiling
closure panel
2"
Fail-safe inertial
safety belt system
Pair of
1
/
8
" aircraft cables
Scissor Lift Dimensions
Mounting brackets with
9
/
16
" dia. holes
Scissors, positioned
on left and right
Stabilizing 3rd
scissor on rear
Fail–safe inertial
safety belt
Typical projector
by others
Typical mounting
hardware—
1
/
2
"
threaded rods
by installer
Drive system
enclosure
Bottom pan
Aero Low Profile Mount
with Universal Bracket
