Front Panel Operation
FRONT PANEL CONTROLS
■
Power ON/OFF - Press POWER (1) to turn
the unit on/off.
■
Loading a Disc - Press OPEN/CLOSE (7)
and set the disc (label side up) onto the
disc tray (4). Push the disc tray gently and
it will close; the unit will begin playback.
■
Ejecting a Disc - Press OPEN/CLOSE button
(7) and the disc tray will slide out. Then
remove the disc and close the disc tray.
■
Stop Playback - Press STOP/PAUSE button
(5), and playback will cease.
■
Resume Playback - Press PLAY (6), and
playback will resume.
FRONT PANEL FEATURES
1 Power Button Turns the unit on and off.
2 Headphone Jack Plug in the headphones here.
3 Display Panel Displays playback information.
4 Disc Tray Place the disk here.
5 Stop/Pause Button Stops or pauses playback.
6 Play Button Begins playback.
7 Open/Close Button Opens and closes the disc tray.
2 7 5 4 3 1 6
