Parts list – Desa CGDV32pR User Manual
Page 41
www.desatech.com
116646-01E
41
KEY
NO.
PART NO.
DESCRIpTION
QTY.
1
1110
Screw #8-3 x 3/8 PPH Zinc
11105
Screw #10 x 1/ Zinc
9
3
11179
Screw #10-4 x 1/4 Zinc
4
4
1137
Screw, Trilab M4 x 8 mm
1
5
14389
Millivolt Valve (Natural Gas)
1
14390
Millivolt Valve (Propane/LP Gas)
1
117370-01
Millivolt Valve (NG-High Altitude))
1
6
1449
Piezo Ignitor
1
7
14500
Brass Fitting
8
1453
Flexible Connector
1
9
14511
Ignitor Bracket
1
10
1458
Brass Elbow Fitting
1
11
104506-5
Orifice (Natural #47)
1
14514
Orifice (Propane/LP #55)
1
1
104509-0
Aluminum Tubing Assy
1
13
6808
Valve Bracket
1
14
687
Switch Bracket
1
15
108886-01
Brass Grate Assembly
1
16
108891-01
Burner
1
17
108084-0
Pilot Assembly (Natural)
1
108084-03
Pilot Assembly (Propane/LP)
1
108084-05
Pilot Assembly (NG-High Altitude)
1
18
**
Burner Base Assembly
1
19
7113
Air Deflector
1
** Not a field replaceable part.
paRTS lIST
BURNER ASSEMBLY MODELS (V)T32N-A, (V)T32NB-A, (V)T32NR-A,
(V)T32NRB-A, (V)T32P-A, (V)T32PB-A, (V)T32PR-A, (V)T32PRB-A, CGDV32NR
AND CGDv32pR
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 36 of this manual.
