X1600 PRO
9650 DeSoto Ave
Chatsworth, CA 91311
Tel: (818) 534-1414
Fax: (818) 773-9619
www.diamondmm.com
Featuring: RADEON TM X1600 PRO
Memory: 256MB/512MB
Slot Type: AGP or PCI Express
With: Dual DVI / TV-Out / HDTV
Viper X1600 Pro
Cinematic 2D/3D Graphics Card
Overview
Diamond, Diamond Multimedia and Stealth are registered trademarks of Diamond Multimedia. ATI, Graphics by ATI, and Radeon are trademarks
of ATI Technologies, Inc. All other trademarks are property of their respective owners. © 2006 Diamond Multimedia. All rights reserved.
LATEST TECHNOLOGIES
Takes advantage of the revolutionary new Avivo video and display technology platform to enable High-Definition visual experience
and enhance digital video, gaming and photos.
CROSSFIRE
• Combined Multi-GPU power for a new dimension
of graphics capability
• High-performance processor sharing
• High compatibility with games, graphics cards,
motherboards, and third party component
AVIVO
• Video and Display Perfection
• True-to-Life Image Reproduction
• Sharp video and photos, smooth video playback
• Universal connectivity for TVs and display
*Crossfire not available with AGP version
*Crossfire not available with HyperMemory TM
*Crossfire only availble on motherboards that support dual PCI Express x16 slots
Features
• 157 million transistors on 90nm fabrication process
• Dual-link DVI
– Twelve pixel shader processors
– Five vertex shader processors
– 128-bit 4-channel DDR/DDR2/GDDR3 memory interface
– Native PCI Express x16 bus interface
- AGP 8x configurations also supported with AGP-PCI-E external bridge chip
– Dynamic Voltage Control
Ring Bus Memory Controller
• 256-bit internal ring bus for memory reads
• Programmable intelligent arbitration logic
• Fully associative texture, color, and Z/stencil cache designs
• Hierarchical Z-buffer with Early Z test
• Lossless Z Compression (up to 48:1)
• Fast Z-Buffer Clear
• Z/stencil cache optimized for real-time shadow rendering
Advanced Image Quality Features
• 64-bit floating point HDR rendering supported throughout the pipeline
– Includes support for blending and multi-sample anti-aliasing
• 32-bit integer HDR (10:10:10:2) format supported throughout the
pipeline
– Includes support for blending and multi-sample anti-aliasing
• 2x/4x/6x Anti-Aliasing modes
– Multi-sample algorithm with gamma correction, programmable
sparse sample patterns, and centroid sampling
– New Adaptive Anti-Aliasing feature with Performance and
Quality modes
– Temporal Anti-Aliasing mode
– Lossless Color Compression (up to 6:1) at all resolutions,
including widescreen HDTV resolutions
• 2x/4x/8x/16x Anisotropic Filtering modes
– Up to 128-tap texture filtering
– Adaptive algorithm with Performance and Quality options
• High resolution texture support (up to 4k x 4k)
