41
WOOL WEIGHT
CERAMIC WOOL
VERMICULITE BAFFLE
REAR AND MIDDLE
TUBES
FRONT TUBE
Figure 4.6.1 (A) – Baffle installation for Millenia
VERMICULITE BAFFLE
1 1/4" X 4 1/2" X 9"
1 1/4" X 4" X 8"
1 1/4" X 4" X 4"
1 1/4" X 4" X 7 5/8"
1 1/4" X 2 1/4" X 9"
1 1/4" X 2" X 9" WHIT HOLE
1
1
2
2
2
2
3
4
3
3
5
3
3
3
3
3
2
2
2
2
2
2
3
5
6
7
6
1
2
3
4
5
6
7
9"
2"
7 1
/1
6
"
1"
O 7/8"
3
Figure 4.6.1 (B) - Firebrick layout for Millenia
