www.desatech.com 116658-01A 37
PARTS LIST
REMOTE-READY MODELS
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 33 of this manual.
KEY
NO.
CDCFPRA CDCFNRA DESCRIPTION QTY.
1 111069-01 111069-01 Dual Burner 1
2 099056-29 099056-34 Injector 1
3 103342-04 111195-07 Outlet Tube 1
4 111124-01 111124-01 Burner Retainer Spring 1
5 097809-02 097809-02 Male Fitting 1
6 103778-01 103779-01 ODS Pilot 1
7 099387-09 099387-12 Pilot Tube 1
8 098249-01 098249-01 ODS Nut 2
9 M11084-26 M11084-26 Screw, HWH AB 10-16 x .38 10
10 ** ** Chamber Floor 1
11 110793-01 110793-01 Piezo Bracket 1
12 102445-01 102445-01 Piezo Ignitor with Palnut Fastener 1
13 101628-01 101628-01 Flexible Connector 1
14 098271-10 098271-10 Ignitor Cable 1
15 M12461-26 M12461-26 Screw, MX SLT WSR 10-32 x 3/8 4
16 111173-01 111173-01 Remote Valve Bracket 2
17 103781-02 103781-01 Gas Valve 1
18 101480-12 101480-12 ASM High Temp Wire 1
19 097809-02 097809-02 Male Fitting 1
20 113342-01 113342-01 Log Set 1
21 -------- 099918-02 Pilot Regulator 1
22 -------- 099387-14 Pilot Tube 1
PARTS AVAILABLE — NOT SHOWN
901056-01 901056-01 Brass Flare Adapter Fitting 1
103470-01 103470-01 Hardware Pack 1
100563-01 100563-01 Warning Plate 1
103877-01 103877-01 Lighting Instruction Plate 1
** Not a field replaceable part
