Dukane Digital Visual Presenter DVP505A - Manual (Page 2)

The DVP 505A is a digital presenter consisting of a
high-resolution color camera on a moveable extendable
arm mounted over a stage with a backlight. There are
also lights on arms located on each side of the stage
for illlumination of the subject. This presenter is very
easy to use and can be controlled by the built-in controls
or via credit card size remote control that is stored in
the presenter's base. It merely requires plugging into
standard power, connection of the computer or video
cable to the projector or display monitor, and the push
of the power button. After that the user can position the
camera arm and push the auto focus button. The DVP
505A has a 12X optical and 4X digital zoom range
controlled by buttons. The camera which has auto focus
can easily view objects at up to 80X magnification. Up
to 32 images can be captured by merely pushing the
"Capture" button on the remote.
Objects such as transparencies can be illuminated from
the backside using the stage lamp or illuminated from
above by the side fluorescent lamps. The presenter is the
perfect tool for providing images of objects, evidence,
papers, X-rays, or demonstrations in the classroom,
conference room, courtroom, at the podium, or for video
conferencing.
Dukane Corporation
Audio Visual Products Division
2900 Dukane Drive
St. Charles, Illinois 60174
Toll-free: 800-676-2485
Fax: 630-584-5156
[email protected]
www.dukcorp.com/av
DVP 505A
Digital Visual Presenter
Specifications DVP 505A
Lens F2.9 to F3.5, FL=5.9mm to 59mm
Shooting Area Range 14.2" x 10.6" to 1.6"x 1.2"
(Transparency 8" x 11"))
Focal Distance 0 to 19" above the stage surface and
to inifinity pointing the camera outward.
Zoom Control Motorized 12x optical and 4x digital
6.7x mechanical, total 80x
Focusing Automatic/Manual
Iris Auto/Fine tune
Side Illumination 2 lamps (1 per side) fluorescent on arm.
Back light, stage Size, 10.6" x 8.2" fluorescent, cold
cathode
Image pickup 1/3" CCD progressive scan
Total pixels effective 1077 (H) x 778 (V), XGA
Synchronization (H) 60k/47kHz, (V) 75Hz
Frame Rate 20 Frame/sec
White Balance Auto/Manual
Exposure Auto/Manual
Freeze Push button operation
Image Modes Photo/Text/Inverse/Grayscale
Image Signal Level 0.7 Vpp
Output Signals RGB analog, XGA 75Hz, SVGA 75Hz,
S-Video, NTSC/PAL, Composite, NTSC/PAL
RGB, Computer D-sub, 15 pin (VGA)
DVI Digital & Analog Connector
S-Video Mini Din 4 pin
Composite Video RCA jack
Audio Stereo mini jack
USB Standard socket, Type B
DC 12V DC jack, 500mA
Mouse Port Standard PS/2, Menu and pointer
RS-232C D-sub 9 pin male
Mic Input Stereo mini jack
Two Programmable
Presets Yes
Menu On Screen
Image Memory 32 Images
Freeze Yes
Gamma Photo/Text/Grey/Film Modes
Accessories Included Wireless full function remote control, power
cable, user manual CD, DVI cable, PS2
mouse, 4 slide holder, negative film holder,
DVI/VGA adapter, computer cable (VGA),
USB cable, and soft carry case.
Safety UL/C-UL, FCC Class A
Weight 9.7 lbs.
Shipping Weight 20 lbs.
Power Requirements AC100-240VAC, 50/60Hz
Dimensions Folded, 20" L x 13.8" W x 4" H
Open, 25.2" L x 13.8" W x 25" H
Key features:
• High Resolution Color Camera
• XGA Computer Output
• Auto Focus, 12X Zoom
• 32 Picture Memory
• Optical and Digital Zoom
• Dual Lamps & Back Light
• Wireless Remote Control
• S-Video & Composite Video Outputs
• Microphone, Audio, and DC12V Power Outlets
Five (5) year limited warranty on parts and labor in North America,
lamp excluded (for other locations, local warranties apply).Includes
Dukane’s FREE 1 year Peace-of-Mind Loaner Program. 5
YR
