Anderson Manufacturing EC Utility Series User Manual
Ec utility series, Standard features, Dimensions
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".

EC Utility Series
• G.V.W.R. - 1,900 #
• Axles - 2,000 # E-Z lube
• G.A.W.R.- 2,000 #
• Suspension - Multi-leaf spring
• Coupler - 2”
• Tires - ST 175-80D-13” load range B
• Safety Chain - 3/16” grade 41 with hooks
• Wheel - 13” 5 bolt white spoke
• Frame - 3”x 2”x 3/16” angle
• Deck - expanded metal
• Crossmembers - top 3”x2” x3/16 angle
• Lights - D.O.T. stop, tail, turn, and clearance
• Fenders - 9” x 32” roll formed
• Elec. Plug - 4- way flat
• Paint - High solids acrylic enamel
Standard Features
13” white spoke rims
36” gate
Dimensions
Trailer size
A
B
C
D
5x8’
98”
60”
16”
60”
5x10’
122” 72”
16”
60”
2
