295
Main Frame Parts Table )
Item Part No. Description 295
1 31625 295 Main Frame Weldment 1
2 48.0" Bucket 1
2 60.0" Bucket 1
3 114534 Stand Weldment 2
4 114536 Strap Stand 2
5 24329 Wrench Mounting 1
6 110907 Pin 0.625 Dia. Stand 2
7 12779 Hair Pin Clip #9 Western Wire 4
8 84162 Cotter Pin 5/32 x 1.000 1
9 114524 Leveling Rod (48.0") 1
10 112954 Pin 1.250 Dia. x 6.750 Long 4
11 113797 Pin 1.000 Dia. X 5.000 Long 4
12 110871 Bushing 1.000 ID x 1 (250 OD x 1.375 LG 4
13 113766 Bushing 1.250 ID x 1,500 OD x 1.375 Long 4
14 24242 Tube Cover 1
15 Bucket Cylinder 2
16 Lift Cylinder 2
17 810640 Bolt Hex 0.313nc x 2.00 gr5 pi 4
18 81581 Bolt Hex 0.375ПС x 2.500 gr5 pi 8
19 81669 Bolt Hex 0.625ПС x 3.500 gr5 pi 2
20 81592 Nut Hex 0.375ПС pi 4
21 81568 Nut Lock (nylon) 0.313nc pi 4
22 113798 Nut Lock (nylon) 0.375ПС pi 12
23 81967 Nut Lock (nylon) 0.625ПС pi 4
24 81570 Washer Flat Std 0.375 hs pi 4
25 112614 ‘Decal - Allied x 1.750 2
26 52281-000 ‘Bright Orange Scotchcal #72368 8.5ft
27 104719 Pin 1.000 Dia. x 6.000 Long
‘Part of decal replacement kit XI296
21
