INSTALLATION GUIDE FOR:

RADIO MODELS

IM-100/IM-200/IM-300

Printed In Korea 1S0-4O75 .

OJN MOUNTING (EXAMPLEiVOLKSWAGON)

SEE FIG. 1

1. Verify opening is within following dimensions;

A. Height 52mm-53mm

3/64'- 2 3/32")

S. Width fsamm-‘104mm (7 5/32" * 71/4*}

2. If opening Is less, carefull file to esoct size

required {DO NOT OVER FILE>

3. Remove din sleeve from radio arid place Into

opening,

4. Bend tabs outward to lock sleeve Into dash.

5. Pre-wire radio. Slide radio into din sleeve until It

locks into place. Note: Use either near bushing

or perforated strap to sstMjre rear of radio.

RADIO REMOVAL {IF NECESSARY)

1, Unsnap trimring on face of radio.

2. Insert removal tool In slotted holes on sides of

radio uritil bottomed. Spread tools outward slightly

and pull radio toward you. Remove tools end

slide radio fully out.

RG.1

TRfMBEZEL (INSTALLED ON RADIO)

HEMOVAl TOOt.
