2. VIDEO COMiWÜNrcATION
(1) Receiving a caii from video door station; (2) Video monitoring;
\i/ \i/
□ G G G D D O D D - g D
BGM VOL voice ' vól ' occupied :’ all ’ calí .’:##':
Depress
MONITOR-
button.
! !
■
!
:
- :
i,D_DDDGDDDOCrtr
” G G 0 □
! : i
1,^^ - 'xi
When video
door station is
connected to
No. 10.
Upon depressing
No. 10 button,
you can have
both audio and
video.
Door station call-in is announced by chime tone and the
image of a caller appears on all video monitors.
Depress a selector button below the illuminated LED.
Depress TALK button to talk and release to listen.
(1) Reply within 20 seconds after chime tone sounds.
Sub call-in annnciator LED goes off in 20 seconds.
(2) After called, the picture remains for approx. 45 seconds.
If picture goes off, depress MONITOR button to have
the picture for approx. 2 minutes and half.
(3) Chime tone is available only when BGR-lOA is used.
MFH-UB LEF-10C
When multiple camera adaptor is used;
Depress MONITOR button on MFH-UB to turn on door
station/camera No. I.
Depress MONITOR button again to have the picture of door
station/camera No.2.
If a door station/camera No.3 is installed, depress MONITOR
button third time (if not installed, picture goes off).
The fourth pressing MONITOR button turns off the picture.
The fifth pressing returns to the No. 1 picture.
1
L.
Notes;
( I ) The picture goes off approximately 2 minutes and half after MONITOR button is pressed.
The picture which comes on after last time MONITOR button is pressed, starts from the door station/camera last monitored
If door station calls in after last monitoring, the next video monitoring starts from the door station/camera No.l.
(2) To monitor the other door station(s);
While communicating with one video door station, you can switch to the picture of the next door station, by pressing
MONITOR button on MFH-UB.
(3) When door station calls in while monitoring, the picture is switched to that of calling door station.
3. MUSIC CENTER (BQR-10A)
INSIDE SETTING
SWITCH SECTION CH,ME TONE
B VOLUME
CONTROL
AUX/TUNER selector switch-
Wnen AUX IS us^ for BGM e^cKGROUND MUSIC
source instead TONE CONTROL
FRONT
PANEL
A
LCD-
LOCAL7DX SWITCH-
BGM VOL-
BGM ON/OFF -
o a a a o o o Q D O
o a a o a a o o a a
□ □□ □ □
MIN HR r--------------------------
s g D □ □ D □
DISPLAY CHANGEOVER -
-ALL CALL VOLUME CONTROL
-BACKGROUND MUSIC DISTRIBUTION
CHIME CALL RECEIVE MASTER SETTING
-RADIO PRESET CHANNEL SELECTION
-TIME SETTING
-RADIO TUNING
(1) BACKGROUND MUSIC (2) CHIME CALL
1. Set the BGM ON/OFF switch to upper ON position. A
2. Set the individual BGM ON/OFF switch for each B
room station.
3. Adjust the MUSIC TREBLE/BASS switch as desired. B
4. Adjust music volume by BGM VOL. switch A
as desired.
1. Set the individual CHIME ON/OFF switch for each B
room station.
2. Adjust CHIME VOLUME switch to the level desired. B
(3) ALL CALL
1. Adjust pre-tone volume to the level desired. B
2. Adjust all call announcement volume to the level B
desired.
