Loader Specifications
(PER ASAE S301.2)
Model number: 695
Mounting height; 39.5” nominal
(Typical range: 40.0”)
Cylinder specifications:
I /
Cylinder
Bore
Rod
Stroke
Bucket
3.00”
1.75”
26.50”
Lifting
3.00”
1.75”
30.00”
Leveling
3.50”
1.75”
12.00”
TSL Bkt
3.00”
1.75”
22.00”
A)
B)
C)
D)
D)
F)
G)
H)
R)
R)
Maximum lift height: 161” (13.4’)
Clearance with bucket dumped: 117” (9.8’)
Reach at maximum height: 21”
Maximum dump angle: 60.0 deg.
TSL max dump angle: 60.0 deg.
D1) TSL dump angle at ground: 90 deg.
F) Bucket rollback angle; 32 deg
TSL bucket rollback angle: 37 deg.
Digging depth: 5.0”
Overall height in carry position: 84.0” (7’)
Rollback angle at full height: 1*21.5 deg.
TSL bucket rollback at full lift: 52 deg.
Calculated breakout force: 5615 lbs.
Calculated lift capacity: 3165 lbs.
M
/°/! f
/®
____ ___ ' 695
GT
7
<^3.7
VJ
V id
/
■W /
0/
oy.u ^
43.00
GROUND LEVEL
12
.
0
-
Notes:
1) Calculated values assume 2500 psi cylinder pressure.
2) Breakout force estimated as per ASAE S301.24.12 (net payload applied at cutting edge).
3) Lift capacity estimated as per ASAE S301.24.11 (net payload applied at bucket midpoint).
4) Average bucket weight (72”): 450 lbs.
Torque Specifications
Recommended torque in Foot Pounds (ft-lbs) & Newton Meters (NM)*
Standeircl
BdtHead
Bolt Dameter
(inches)
Wench
Sze
(inches)
0
©
Grade2
(ft4bs)(MVI)
Grade5
(fl4bs)(NIVI)
Gnade8
(fl4bs)(MVI)
0.250
1/4
7/16
6
7
8
11
12
16
0.313
5/16
1/2
11
15
17
23
25
33
0.375
3/8
9/16
20
27
31
42
44
60
0.438
7/16
5/8
32
43
49
66
70
95
0.500
1/2
3/4
49
66
76
103 106
144
0.563
9/16
7/8
70
95
109
148 153
207
0.625
5/8
15/16
97
131
150
203 212
287
0.750
3/4
11/8
144
195
266
360 376
509
0.875
7/8
15/16
166
225
430
583 606
821
1.000
1
11/2
250
339
644
873 909 1232
1.125
11/8
111/16 354
480 795 1077 1288 1745
1.250
11/4
17/8
500
678 1120 1518 1817 2462
1.375
13/8
21/16
655
887 1470 1992 2382 3228
1.500
11/2
21/4
870
1179 1950 2642 3161 4283
Metric
Bdt
Da.
(mm)
V\iiench
Sze
(mm)
BdtHead
Q Q 0
Qass4.6
(1l4bs)(NM)
Qass8.8
(ft4bs)(NM)
Qass9.8
(ft4bs)(NM)
8
13
7.3 10
21.1 29
10
16
14.5 20
42 57
12
18
25 34
74 100
73 99
14
21
40 54
118 160
116 157
16
24
62 84
167 226
181 245
20
30
122 165
325 440
22
33
443 600
24
36
211 286
563 763
27
41
821 1112
30
46
418 566
1119 1516
*Use 80% of the specified torque value for
plated lubricated fasteners.
