Adams Speedflame Power Gas Burner - Manual (Page 2)

REDUNDANT GAS VALVE
ProvKtes bacK-up vaNe for
acM«d safety
EUECTRONtC PRIMARY
CONTROL
Meets the most stnngent
ñame supervision specffica-
lions. Flame provinQ wKhtn
four (4) sacorxto: supervises
ell Igniüon functions inducing
.8 of e secorxf rebght capability;
senses flame by rectification,
providing positive flame
monitoring
PRESSURE SWITCH
Field- proven motor swtfch
ensures blower operation
FLAME RETENSKDN HEAD
Adams time>pro\«n. precision
head posHrveAeiy locks №e
flame on the burner heed
to optimize efficient burner
performance
AIR TUBE 4“ DIAMETER
6" Length standard, please
consult the factory for other
lengths
MANIFOLD PRESSURE
REGULATION
C.SA Design Certified
for operation at
W.C. for Natural and
LP. gases.
EXTERNAL ORIFICE CHANGE
Adams special orifice in the
manifold union permits orifice
change without disassembling
the burner.
HIGH VOLTAGE IGNmON
TRANSFORMER
Provides the most dependttie
direct spark ignition system
tvaflable
POSITIVE-LOCK AIR CONTROL
Dual shutter and numericBl scale
for precise air Inlet adjustment.
PATENTED VACUUM MIXING METHOD
Adams innovative vacuum mix of air and
fuel gives you the ultimate In combustion
perform wice.
Specifications
-
Model G2T
4” Blast Tube
Capacity 50M to 850MBtu/Hr
Natural Gas
Capacity M/BTU
Mode) Max Min
Combination
Gas Valve I c i n i t i o n M o r o r H P
G2T-300 300 50 y«" 2000DERHC Direct Spark
1/r
G2T-600 600 50 Vi" VR8304M Direct Spark 1/7
G2T-850 860 200 1" 7000ERHC Direct Spark 1/7 '
L.P. Gas
G2T-400LP 400 60 Va” 2000DERHCLP Direct Spark 1/7*
G2T-850LP 850 200 %” VR8304MLP Direct Spark 1/7
*Air Spoiler Installed
Dimensions: Height 17" - Width 13" - Depth (Chassis only) 8"
ADAMS
Manufacturing Company
9790 Midwest Avenue • Cleveland, Ohio 44125
Telephone (216) 587-6801
FAX (216) 587-6807
Form 62
E-Mái; adamsx@atlnet
