595, S595, 595 HSL, S595 HSL, 595 TSL, & S595 TSL
Sub Frame Parts Table
Regular HSUTSL
Description
Quantity Quantity
item Part No.
S595
Quantity
S595 HSUTSL
Quantity
1
31423
595 Sub Frame Weldment Left
1
-
2
31424
595 Sub Frame Weldment Right
1
-
-
-
1
31425
595 HSL Sub Frame Weldment Left
-
1
-
-
2
31426
595 HSL Sub Frame Weldment Right
-
1
-
-
1
31437
595 S Sub Frame Weldment Right
-
-
1
-
2
31438
595 S Sub Frame Weldment Left
-
-
1
-
1
31439
S595 HSL Sub Frame Weldment Left
-
-
-
1
2
31440
S595 HSL Sub Frame Weldment Right
-
-
-
1
3
110959
Hook Weldment
2
2
2
2
4
112747
Plate Clamp
2
2
2
2
5
112746
Spacer Block
4
4
4
4
6
112748
Shim
2
2
2
2
7
112663
Cross Member Weldment
1
1
1
1
8
112668
Tube Cross Member
1
1
1
1
9
112642
Shaft Pivot 1.75 DIAX 5.50 Long
2
2
2
2
10
113281
Bolt Retainer Weldment
2
2
2
2
11
110887
Loader Lift Lock Weldment
2
2
2
2
12
812717
Grommet 0.375 ID X 1.00 OD X .13
2
2
2
2
13
812026
Bolt Hex 0.313nc X 1.00 gr5 pi
2
2
2
2
14
812944
Bolt Car. 0.625nc X 3.00 gr5 pi
8
8
8
8
15
84127
Bolt Car. 0.625nc X 3.50 gr5 pi
2
2
2
2
16
812939
Bolt Hex 0.875nc X 10.00 gr8 pi
2
2
2
2
17
81967
Nut Lock (nylon) 0.625nc grB pi
14
14
14
14
18
81723
Washer Lock 0.875 pi
2
2
2
2
19
112730
Washer Boot
2
2
2
2
20
112812
‘Decal General Caution
2
2
2
2
21
113228
‘Decal -595 X 1.40
2
2
2
2
22
112983
‘Decal
-
Warning Overhead Hazard
2
2
2
2
23
112982
‘Decal - Lift Lock Instruction
2
2
2
2
24
812882
Bolt Car. 0.625nc X 2.50 gr5 pi
4
4
4
4
25
113474
‘Decal
-
Cross Member Caution
2
2
2
2
26
24329
Mounting Wrench (for 0.875 bolt)
-
1
1
1
27
112615
‘Decal - S
X
1.40
-
-
1
1
‘Part of decal replacement kit XI256
