PARTS LIST
This list contains replaceable parts used in your stove. For replace-
ment parts see Replacement Parts on page 17 of this manual.
PARTS LIST
Models CSB Series, CSPB Series, and CSPI Series
KEY
PART NUMBER
NO.
CSB Series
CSPB Series
CSPI Series
DESCRIPTION
QTY.
(Black)
(Porcelain Black)
(Porcelain Ivory)
1
111698-07
111698-08
111698-09
Top Grate - Center
1
2
111698-11
111698-12
111698-13
Bottom Door
1
3
111531-01CK
111531-01CK
111531-01CK
Stove Dropped Pan (Black Only)
1
4
111698-14
111698-15
111698-16
Left Stove Door
1
5
111698-17
111698-18
111698-19
Right Stove Door
1
6
111698-20
111698-21
111698-22
Stove Leg
4
7
111764-01
111764-01
111764-01
Hardware Kit
1
8
111533-01
111533-01
111533-01
Screen Rod
1
9
111532-01CK
111532-01CK
111532-01CK
Stove Back Panel (Black Only)
1
10
111698-23
111698-23
111698-23
Door Knob
1
11
103297-04
103297-04
103297-04
Screen
1
PARTS AVAILABLE — NOT SHOWN
104108-08
—
—
Touch-up Spray Paint 12 oz Can, Black
1
* Included In Hardware Kit
