Appendix Service manual WP-795
- 5 -
TV processor version and
µ
-Controller capacity
IC version TDA9365 Nx / 5
TV range 110°
QSS sound IF amplifier with
separated input and AGC circuit
9
PAL decoder
9
SECAM decoder
9
NTSC decoder
9
Horizontal geometry (E-W)
9
Horizontal and vertical zoom
9
ROM size 96 k
RAM size 2 k
Teletext 10 pages
IC marking and version
Chassis IC marking
( line 3 )
OSD languages ATSS country Text
English, French,
German, Italian,
Spanish, Dutch,
Danish, Finnish,
Norwegian,
Swedish, Greek,
Hungarian English,
German,
Swedish/Finnish/Hu
ngarian, Italian,
French,
Portuguese/Spanish,
Turkish, Greek
Polish, Czech,
Slovakian,
Romanian Polish, German,
Estonian,
Serbian/Croatian/Sl
ovenian,
Czech/Slovak,
Rumanian
WP 795 DW9365/N1/5-BE x
( note : x is the
software version )
Russian
GB, France,
Germany,
Belgium, Spain,
Italy,
Switzerland,
Austria,
Denmark,
Finland,
Netherlands,
Norway,
Sweden, Ireland,
Poland,
Hungary, Czech
rep., Others
Polish, German,
Estonian,
Russian/Bulgarian,
Serbian/Croatian/Sl
ovenian,
Czech/Slovak,
Rumanian
PINNING
SYMBOL PIN DESCRIPTION
n.u. 1 Port 1.3 Not used.
SCL 2 I2C bus clock line
SDA 3 I2C Data line
SECAM L’ out 4 Port 2.0 : High when L’ selected (Push Pull )
OCP 5 Port 3.0 : Over Current Protection
