CHAMPION ST762E - Manual

C
hampion
'
Power SLforce
Иллюстрированный каталог запасных частей Модель: ST762E
№ Артикул Наименование К-во № Артикул Наименование К-во
1 SJ-205B Handle assembly 1 26 ST762E-26 plain cushion 4
2 SJ-217 Handle sleeve 2 27 ST762E-27 hexagonal Nut 2
3 SJ-221 cam Connecting handle 2 28 ST762E-28 lock nut 2
4 SJ-222 handle spring 1 29 SJ-028 SJ Handle mat 2
5 SJ-203 cam bracket (right) 1 30 ST762E-30 hexagonal Screw 2
6 SX-11-03 clutch 1-1 2 31 ST762E-31 hexagonal Screw 2
7 SX-11-02 clutch 1-2 1 32 SJ-026 SJ Head shaft bushing 2
8 SJ-204 cam bracket (left) 1 33 SJ-003 SJ Large gear 1
9 SJ-222-1 handle twist spring (left) 1 34 ST762E-34 Semicircular key 2
10 SJ-205A adjusting crank 1 35 ST762E-35 Pin 1
11 SX-11-007 spring 3 1 36 SJ-017 SJ Drive wheel axle 1
12 SJ-213 Dead plate welding drawing 1 37 SJ-066 SJ Spring Pin 2
13 SJ-241 Adjusting lever handle 1 38 ST762E-38 plain cushion 2
14 SJ-209-4 Adjusting joint rod 2 39 SB-21 Tyre 1
15 SJ-209 Adjuster lever welding drawing 2 40 SJ-134 Gasoline Engine 1
16 SJ-215 U fiche 6 41 ST762E-41 hexagonal Screw 2
17 SJ-224 Pear-Shaped fiche 6 42 ST762E-42 plain cushion 2
18 SJ-068A SJ control arm 1 43 SJ-031 SJ Pulley Cover 1
19 ST762E-19 Saddle elastic washer 4 44 ST762E-44 lock nut 4
20 SJ-210-2 Adjuster damp fixing plate 2 1 45 ST762E-45 plain cushion 4
21 SJ-223 Bowl shrapnel 4 46 ST762E-46 plain cushion 2
22 ST762E-22 hexagonal Screw 1 47 SJ-214 Gear lever fixed hub 1
23 SJ-042-2 Handle 1 48 SJ-211 Gear frame welding drawing 1
24 SJ-210-1 Adjuster damp fixing plate 1 1 49 SJ-233 wire pin 5
25 ST762E-25 Operation Panel 1 50 ST762E-50 hatch pin 5
