40-4328
Weighing Indicator
Physical Dimensions
170/6.69"
AO-4328 WEIGHING INDICATOR
•<
88B888 lb
kg
ZERO MO OAOSS NTT PT
o o
o
Q© GD ©
fouSìì fìCToì Ì t «»
Front View Side View
+1
Unit : mm / inches
162±0.5/6.38±0.02'
Cut Out
Specifications
Input Sensitivity -
Power
Input Signal Range
Loadcell Excitation
0.2p/d (Min.)
-ImV - +15mV
■5V DC ±5%
Loadcell Drive Capacity — Up to 6 load cells at 350fl/load cell
(Max.90mA)
Zero Temperature Coeffdent--- ±(0.2pV+0.0008% of dead load)/*C (typ.)
Span Temperature Coeffdent---±8ppm rc of reading (typ.)
■0.010/ooffuliscaie
■ ±0.2pVp-p
• 10MQ ± or more
• int^ating dual-siope type
- 40,000 counts (Max.)
• Approximately. 10 times/second
- edigits, 14.2mm / 0.56" (H) LED
■ 20,000 counts (Max.)
■ Times XI, X2, X5, XI0, X20, X50
500000
- minus display
- ZERO, MD, CROSS, NET,
PRESET TARE, kg/t or kg/lb
- STANDBY/OPERATE, NET/CROSS, PRESET
TARE, ZERO, M+, TARE, MODE, PRINT
Non-Linearity---------------
Input Noise------------------
Input Impedance----------
A/D Conversion Method
/V/D Resolution -----------
A/D Conversion Rate -
Weight Display--------------
Display Resolution —
Minimum Division ---------
Maximum Display----------
Under ZERO Indication
Annuciation------------------
Keys
Net Weight ----------------
Operating Temperature
Storage Temperature
Physical Dimensions
Panel Cut out Dimensions
Standard Accessories
Options
OP-01 —
OP-02 —
OP-03 —
OP-04 —
OP-10 -
-DC 9V
(AC Adaptor or direct input to the lermial)
- Approximately 0.8 kg /1.8 lb
--lO'C-AO'CiU'F- 104'F)
--10°C--70‘’C(14°F- 158 °F)
- 170(W) X 126 +19" (D) X 130(H) mm
•|ncl. terminal cover
-124 ±0.5 X 162 ±0.5 mm
- Manual, AC Adaptor
BCD Output (Open Collector)
Comparator Output (Open Collector)
RS-422/485 with Relay Output
RS-232C/Current Loop/Relay Output
Display Stand
Only one output can be selected from OP-01, OP-02, OP-03 and OP-04.
One to be choosen from RS-422 or 485.
Accessories
AC Adaptor — TB164 (220V)
Specifications subject to change for improvement without notice.
