2.2 Mechanical
Display

Battery state-of-charge: 10-bar, tri-color LED

Hour Meter: 6-digit LCD, 5mm high

Resolution

Hour Meter

99,999.9 Hours

Hardware Kit

Mounting bracket, thumbnuts or M4 Hex nuts (2),
lock washers (2), mating connector Molex
No. 39-01-2085, w/pins No. 39-00-0039, no
connectors in bulk shipments.

Panel Cutout

52mm, 2

” diameter
