Agri-Fab 45-0308 - Manual (Page 3)

Ref.
No.
Part
Number Description
Qty.
Req.
1 HA24000 Engine 1
2 HA22819 Guide - Belt 1
3 43085 Bolt, 5/16-18 X 1-1/2" Hex Head 4
4 HA115321 Screw, 5/16-18 X 5/16" Cup Pt. Set 1
5 HA11154 Key, Square 3/16" x 2" 1
6 HA20176 Pulley 1
7 HA23738 Bracket, Lift Stop 1
8 HA20169 Bolt - Shoulder 1
9 HA19860 Spring, Depth Extension 1
10 HA20701 Hitch Bracket Assembly 1
11 43063 Bolt, 5/16-1 8 X 1" Hex Head 10
12 43064 Locknut, 5/16-18 Hex 25
13 HA20679 Lift Handle Assembly 1
14 HA15683 Screw, Self-Tapping 1/4" x 1/2" 1
16 HA20135 Ring, Retainer 1
17 HA20184 Pulley, Input 1
18 HA20178 Bolt - Shoulder 1
19 HA103373 Pin, Cotter 3/32" X 3/4" 3
20 HA20180 Clutch Rod Assembly 1
21 HA20167 Bracket, Clutch Control 1
22 HA20168 Lever, Clutch 1
24 HA20170 Grip, Handle 2
25 HA20162 Bracket, Guide - LH 1
26 HA20134 Bracket, Belt Guide & Idler Mounting 1
27 43082 Locknut, 3/8-16 Hex 10
28 43661 Bolt, 1/4-20 X 1" Hex Head 7
29 HA20185 Key, Woodruff No. 61 1
30 HA20163 Bracket, Guide - RH 1
31 HA20119 Transmission - Complete 1
32 HA20160 Chassis, Left 1
33 HA20186 Spring, Extension 1
34 HA20159 Chassis, Right 1
35 HA23258 Bracket, Idler 1
36 HA11496 Pulley, Idler 1
37 HA20187 V-Belt 1
38 HA4119 Nut, 1/4-20 Hex Lock 8
39 HA20936 Tine Shield Assembly - LH 1
40 43182 Bolt, 5/16-18x3/4" Hex Hd. 8
41 HA20112 Rear Guard Assembly - LH 1
42 HA20118 Connecting Pin, Rear Guard 2
43 HA20113 Rear Guard Assembly - LH 1
44 HA20094 Tine & Hub Assembly - RH 1
45 HA20088 Tine & Hub Assembly - LH 1
46 HA10070 Pin, Clevis 4
Ref.
No.
Part
Number Description
Qty.
Req.
47 HA3430 Hair Cotter Pin 2
48 HA20935 Tine Shield Assembly - RH 1
49 43062 Bolt, 3/8-16 X 1-1/2" Hex Head 4
50 HA20918 Wheel 2
51 R74780828 Bolt, 1/2-13 X 1-3/4" Hex Head 1
52 HA20670 Pivot Axle Assembly 1
53 *GM-126227 Bolt, 3/8-16 X 3/4" Carriage 4
54 HA20725 Strap Frame Extension 2
55 HA3433 Pin, Clevis 2
56 HA20690 Stake, Drag 1
57 HA446363 Washer 1
58 43177 Lockwasher, 1/4" Med. 1
59 HA20316 Plate, Fender Support 1
60 HA20941 Decal, Caution Flag 1
61 41576 Bolt - 3/8-16 X 1-3/4" Hex Head 1
64 HA20704 Belt Guard (incl. #69) 1
65 HA14306 Washer 1
66 HA20691 Strap-Frame Extension Brace 1
67 43262 Nut, 1/2-13 Hex Lock 3
68 HA20938 Decal, Danger 2
69 HA20942 Decal 1
70 HA5713 Spacer 1
71 HA15200 Washer 2
72 HA180173 Bolt, 1/2-13 X 1" Hex Head 1
73 HA13780 Anchor - Spring 1
74 HA21366 Rod - Lift Anchor 1
75 HA120123 Pin -1/8" X 1-1/4" Cotter 6
76 HA20688 Rod - Lift 1
77 HA19649 Anchor - Adjustment 1
78 HA120396 Washer -17/32" x 1-1/6" x .095" Flat 1
79 HA124934 Nut -1/2-20 Hex Jam 2
80 HA456151 Washer -13/16" x 1 -1 /2" x . 134" Flat 2
81 HA20481 Pin - Hair Cotter 6
82 HA7974 Spacer 2
83 HA445608 Bolt, 1/2-13 X 5-1/2" Hex Head 1
84 44326 Bolt, 5/16-18 X 1" Carriage 2
85 HA20932 Bracket - Wheel Weight Support 2
86 HA20940 Decal, Danger 1
87 HA5236 Pin - Locating 1
88 HA3341 Pin - Hair Cotter 1
89 HA20173 Flag, Caution 1
90 HA20172 Bracket, Caution Flag 1
91 HA21362 Nut, Hex Nylock 3/8-16 9
NP HA24038 Owner's Manual 1
3D
m
■D
>
■ D
>
3D
H
Ui
■n
o
3D
o
D
m
1“
cn
■ o
CO
o
00
00
o
■
lO
00
cn
CD
m
*Standard Hardware - Purchased Locally
