Aphex Modular System
Power Supplies
Models 9000PS/9001PS/9005PS
Power Consumption Planner
As is commonly known, quality audio processing starts with enough current headroom
to supply the most extreme audio swings on demand. With the wide variety of
processing modules available for the 9000 Series, it might be necessary to calculate the
current consumption of your modules to make sure that the audio quality is not
compromised by the limits of the power supply.
A p h e x ± 1 5 v
8126
9251
9301
9611
9651
9721
9901
350mA
125mA
300mA
230rnA^
”260mA
330mA
107mA
All figures measured max current
d b x ± 1 5 v ± 2 4 v
902 60mA 30mA
903 60mA 30mA
904 60mA 30mA
905 60mA 30mA
911 50mA 26mA
929 75mA 65mA
933 60mA 90mA
941A 50mA 26mA
942A 50mA 26mA
I m p o r t a n t :
the Aphex Model 9000PS
supplies ±15V at 3A, Model 9005PS
supplies ±15V at 5A, Model 9001 PS
adds ±24V at 1.5A for dbx
compatability. The dbx F900A
mainframe provides 1A at +15V/DC,
0.5A at ±24V/DC (dbx power
specifications from their published
literature).
R a c k # 1
Slot 1
_Power_Consum£ti^^
M o d e l C o n s u m p t i o n ( m A )
Slot 2
Slot3
Slot 4
Slots
Slot 6
Slot 7
Slots
Slot 9
Slot 10*
Slot 11*
Total Rack 1
R a c k # 2
Slot 1
Slot 2
Slot3
Slot 4
Slots
Slots
Slot 7
Slot 8
Slot 9
Slot 10*
Slot 11*
Total Rack 2
* Aphex Model 9000 Rack only.
S Y S T E M S 11068 Randall Street »Sun Valley, CA 91352 . (818) 767-2929 »FAX (818) 767-2641
Aphex is proudly American... 100% owned, engineered and manufactured in the U.S.A.
dbx is a registered trademark of Carillon Electronics Corporation
Aphex is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made
from time to time to existing products without prior notice. Specifications and appearance may differ from those listed or shown.
Part No. 02-9000PS-04 Printed in U.S.A.
