Bradford-White Corp 65T65 - Manual (Page 7)

Item Description Model Model Model Model Model
M1XR403S*F(BN,CX,SX) M2XR504T*F(BN,CX,SX) M430T*F(BN,CX,SX) M4403S*F(BN,CX,SX) M440T*F(BN,CX,SX)
1 Draft Hood 243-45787-00 243-33081-02-20 243-45787-00 243-45787-00 243-45787-00
2 Hot Water Outlet Anode MagnesiumA 224-32731-81 224-32731-86 224-32731-95 224-32731-81 224-32731-95
Hot Water Outlet Aluminum A 224-32999-31 224-32999-30 224-32999-24 224-32999-31 224-32999-24
Hot Water Outlet A420 Aluminum A 224-45147-04 224-45147-01 224-45147-02 224-45147-04 224-45147-02
3 Cold Water Inlet Dip Tube PolypropyleneA A 229-39625-03 229-39625-18 229-39625-23 229-39625-03 229-39625-25
Cold Water Inlet Polysulfone (NC Code)A A 229-39628-03 229-39628-18 229-39628-26 229-39628-03 229-39628-28
4 Flue Baffle 243-45223-00 243-41037-00 243-44639-00 243-45223-00 243-42283-00
5 T&P Relief Valve 265-32920-01 230-40594-02 230-40594-02 230-40594-02 230-40594-02
6 Gas Valve Natural Gas 265-46181-01 265-46181-04 265-46181-02 265-46181-02 265-46181-02
Gas Valve LP Gas 265-46182-01 265-46182-02 265-46182-02 265-46182-02 265-46182-02
7 Piezo Igniter 239-43448-00 239-43448-00 239-43448-00 239-43448-00 239-43448-00
7A Piezo Bracket (White Rodgers) 239-46157-02 239-46157-02 239-46157-02 239-46157-02 239-46157-02
Piezo Bracket (Robertshaw) 239-43449-00 239-43449-00 239-43449-00 239-43449-00 239-43449-00
8 Brass Drain Valve 265-42351-02 265-42351-02 265-42351-02 265-42351-02 265-42351-02
9 Screw-#8-18x 3/4 HWH 239-44195-00 239-44195-00 239-44195-00 239-44195-00 239-44195-00
10 Screw-#10-12 X 3/4 HWH 239-44113-00 239-44113-00 239-44113-00 239-44113-00 239-44113-00
11 Left Side Inner Door Complete 239-43968-18 239-43968-18 239-43968-14 239-43968-18 239-43968-16
12 Nat. Gas Right Side Inner Door Complete 239-43963-07 239-43963-07 239-43963-02 239-43963-07 239-43963-05
LP Gas Right Side Inner Door Complete 239-43963-07 239-43963-07 239-43963-02 239-43963-07 239-43963-04
13 Nat. Gas Resettable Thermal Switch 239-43676-02 239-43676-02 239-43676-03 239-43676-02 239-43676-03
LP Gas Resettable Thermal Switch 239-43676-02 239-43676-02 239-43676-03 239-43676-02 239-43676-02
14 Screw-#6-20 X 3/8 PHCR 239-43967-00 239-43967-00 239-43967-00 239-43967-00 239-43967-00
15 Outer Door 243-43962-00 243-43962-00 243-43962-00 243-43962-00 243-43962-00
Natural Gas (BN) Burner Assembly
16 Nat Gas Burner Assembly Complete*** 265-47439-07-32 265-47439-07-27 265-47439-02-36 265-47439-07-32 265-47439-04-32
17 Nat. Gas (BN) Burner** 228-42506-00 228-42506-00 228-42506-00 228-42506-00 228-42506-00
18 Nat. Gas (BN) Main Burner Orifice** 234-41034-32 234-41034-27 234-41034-36 234-41034-32 234-41034-32
Nat. Gas (BN) High Altitude 2001 Ft. to 5000 Ft.** 234-41034-36 234-41034-29 234-41034-39 234-41034-36 234-41034-36
Nat. Gas (BN) High Altitude 5001 Ft. to 8000 Ft.** 234-41034-38 234-41034-30 234-41034-41 234-41034-38 234-41034-36
Nat. Gas (BN) High Altitude Over 8000 Ft.** 234-41034-38 234-41034-31 234-41034-43 234-41034-38 234-41034-38
19 Nat. Gas Pilot Assembly** 233-46277-04 233-46277-04 233-46277-04 233-46277-04 233-46277-04
20 Nat. Gas Pilot Orifice** 234-46502-05 234-46502-05 234-46502-05 234-46502-05 234-46502-05
21 Thermocouple** 233-46501-15 233-46501-24 233-46501-15 233-46501-24 233-46501-15
LP Gas (SX) Titanium Stabilized Stainless Steel Burner Assembly (Replacement for LP Gas (CX) Cast Iron Burner)
22 LP Gas Burner Assembly Complete*** 265-47440-11-50 265-47440-12-43 265-47440-02-60 265-47440-11-50 265-47440-05-52
23 LP Gas (SX) Burner** 228-46964-00 228-47000-00 228-46964-00 228-46964-00 228-46964-00
24 LP Gas (SX) Main Burner Orifice** 234-47064-50 234-47064-43 234-47064-60 234-47064-50 234-47064-52
LP Gas (SX) High Altitude 2001 Ft. to 5000 Ft.** 234-47064-51 234-47064-46 234-47064-54 234-47064-51 234-47064-53
LP Gas (SX) High Altitude 5001 Ft. to 8000 Ft.** 234-47064-52 234-47064-47 234-47064-54 234-47064-52 234-47064-54
LP Gas (SX) High Altitude Over 8000 Ft.** 234-47064-53 234-47064-47 234-47064-54 234-47064-53 234-47064-54
25 LP Gas Pilot Assembly** 233-46278-03 233-46278-03 233-46278-03 233-46278-03 233-46278-03
26 LP Gas Pilot Orifice** 234-46502-02 234-46502-02 234-46502-02 234-46502-02 234-46502-02
27 Thermocouple** 233-46501-15 233-46501-24 233-46501-15 233-46501-24 233-46501-15
28 ASSE Approved Mixing Valve (Optional) 239-43740-01 239-43740-01 239-43740-01 239-43740-01 239-43740-01
29 3/4 NPT Plug 239-11638-00 239-11638-00
30 Inner Door Gasket Kit 239-44078-00 239-44078-00 239-44078-00 239-44078-00 239-44078-00
31 Wire Tie 239-44328-00 239-44328-00 239-44328-00 239-44328-00 239-44328-00
32 Heat Trap Insert (Outlet) 239-45167-00 239-45167-00 239-45167-00 239-45167-00 239-45167-00
33 Heat Trap Insert (Inlet) 239-45073-00 239-45073-00 239-45073-00 239-45073-00 239-45073-00
34 Kit-Heat Trap Insert 265-45420-00 265-45420-00 265-45420-00 265-45420-00 265-45420-00
- LP to Natural Gas Conversion Kit (Norm Alt.) 265-45712-05 265-45712-12 265-45712-09 265-45712-11 265-45712-10
- LP to Natural Gas Conversion Kit (High Alt.) 265-45712-17 265-45712-24 265-45712-21 265-45712-23 265-45712-22
*Applies to all warranties
**lnner door gasket kit recommended
***Orderlng a complete burner assembly may Increase delivery time. Please order the specific component required for the quickest delivery.
A Order with Item 32
▲ ▲ Order with Item 33
Page 7
