6 T Equipment Pipe Rail Series
• G.V.W.R.-12,000 #
• Axles - 2-6,000 # cambered brake axles
• G.A.W.R.(Each Axle) - 6,000 #
• Suspension - Slipper spring with equalizer
• Coupler - 2 - 5/16” adjustable
• Tires - ST 235 / 80R 16”load range D
• Safety Chain - 3/8” grade 43 with hooks
• Wheel -16” 8 bolt white spoke
• Jack -10,000 # drop leg
• Deck - 2” pressure treated pine
• Frame - 5” angle w/ H.D.2 1/2” pipe rail
• Lights - D.O.T. stop, tail, turn, and clearance
• Crossmembers - 3” channel
• Elec. plug - 7-way RV
• Fenders - 10”x72” diamond plate with backs
• Paint - high solids acrylic enamel
• Tongue - 6” channel wrap around
• Ramps - 4’ fold down
• Bed witdth - 81”
• Sealed modular wiring harness
Standard Features
Optional Features
• 16” white spoke
• Steel deck
• Pressure treated decking
• 48” split gate
• Light protectors
• Self cleaning dovetail
• Electric breakaway
• D-Rings
• E-Z Lube axles
Dimensions
Length
A
B
C
. D
E
12’
144”
95.5”
43”
25”
81”
14’
168” 107.5”
43”
25”
81”
16’
192” 119.5”
43”
25”
81”
18’
216”
131.5”
43”
25”
81”
20’
240”
143.5”
43”
25”
81”
22’
264”
155.5”
43”
25”
81”
18
