BOYtr
Thank you for your choosing this product
3" TFT Rearview Monitor
VTM3000
User's manual
1.Parts list
B
Monitor magic plasterxl
C
user's manualx 1
2. Function introduction
High definition 3 inch coior TFT-LCD monitor
Automaticaiiy shift rearview system when reversing the car
Automaticaliy wake up reversing rearview display
When there's no signal, monitor will turn to sleep mode.
Beautiful design____________________________ '
The monitor design matches well with the product
quality. It looks so elegant as much as the monitor
quality stands for. The unique face aims to best fit
to the environment decorative to any place. It can
be placed on the dashboard or onto the windshield.
Specification
Model
VTM3000
Display resolution(dot)
960(W)
X
240(H)
Screen size(inch)
2.96 (Diagonal)
Color configuration
R.G.B. delta
Working voltage
12V
Power consumption
8W MAX
Working environment
-20° C~-H65° C
Display function
Auto reversing rearview monitor
3. Dimension & wiring
