MODE.

Ti

Ti

l/<

ITEM

NO.

PART NO. DESCRIPTION

QTY.

REQ'D

1

Upper Housing Assembly:
(Includes Upper Housing, Housing Screws,

and Switch Actuator)

1a

23202

Upp. Hsg. Assembly Inferno Red

1

1b

23203

Upp. Hsg. Assembly Chrome

1

2

Lower Housing Assembly
(Includes Lower Housing, Tension Spring,
Housing screws, and Blade Yoke)

2a

22954

Lower Housing Assembly/Black

1

2b

23204

Lower Housing Assembly/Black W/ Soft
Grip

1

3

22913

Transformer

1

4

22939

Switch

1

5

22941

Motor Assembly

1

(Includes Motor, Cam, Guide Block, and
Blade Yoke)

6

22943

Battery Assembly

1

(Includes Battery (NIMH), LED, and Input
Connector Jack)

7

23206

Circuit Board/LED Assembly

1

ITEM NO.

PART

NO.

DESCRIPTION

QTY.

REQ'D

IMPORTANT INFORMATION

When ordering repair parts, include part number, part name and model of trimmer. For best performance, trimmer blades should be CLEANED and OILED with

Andis Clipper Oil before and after use, If repair is necessary, return to any Andis Authorized Repair Service Station, or to Andis Company, 1800 Renaissance Blvd.,

Sturtevant, Wisconsin, 53177 U.S.A.. Pack carefully, mail either Insured Parcel Post, or U.P.S. , attach a letter to outside of package explaining difficulty.

Rev-A 11/22/2006

FORM 23201 Rev-A.xls
