Models 692, 693, 694
and 24695
PARTS LIST FOR LEAF BLOWER MODELS 692, 693, 694 and 24695
Ref.
No.
Part
No. Color
Code
Description
New
Part
1 749-0479 Upper Handle
5 714-0114 Sq. Key 1/4" x 1/4" x 2.00" Lg.*
6 710-0442 Hex Bolt 5/16-18 X 1.50" Lg.*
7 14526- - 488 Engine Mounting Frame Ass'y-
8 736-0119 L.-Wash. 5/16" I.D.*
9 712-0267 Hex Nut 5/16-18 Thd.*
10 736-0187 Fl.-Wash. .63" I.D. x 1.25" O.D.
11 1544-009 Cotter Pin 5/32" Dia. x 1.25" Lg.*
12 712-0206 Hex Nut 1/2-13 Thd.*
13 736-0921 L.-Wash. 1/2" I.D.*
14 734-1036 Swivel Caster Wheel 5" Dia. x 1.25"
15 14571 - 488 Caster Arm Ass'y-
16 710-0726 Hex Wash. Hd. "AB" Tap Scr. 5/16" x .75" Lg.
17 14529 -488 Caster Arm Bracket
19 734-1035 Wheel Ass'y. Comp. 12" x 3" (692, 693 & 694)
(Incl. Ball Bearings)
734-1044 Wheel Ass'y. Comp. 11" x 4" (24695 Only)
741-0313 Bearings (24695 Only)
20 736-0159 Fl.-Wash. 34" I.D. x .87" O.D.
21 710-0170 Hex Locking Bolt 5/16-24 x .62" Lg.
22 736-0162 Fl.-Wash.
23 712-0267 Hex Nut 5/16-18 Thd.*
24 736-0119 L.-Wash. 5/16" I.D.*
25 736-0119 L.-Wash. 5/16" I.D.*
26 712-0267 Hex Nut 5/16-18 Thd.*
27 710-0118 Hex Bolt 5/16-18 X.75" Lg.*
28 14561 Index Plate
29 09966 Hand Knob
30 710-0118 Hex Bolt 5/16-18 X .75" Lg.*
31 720-0142 FI.-Grip Vinyi
32 14552 Height Adj. Handle
34 749-0481 Lower Handle
35 7ia0487 Carriage Bolt 5/16-18 x 2.0" Lg.
*For faster service obtain standard nuts, bolts and washers locally. If these items cannot be
obtained locally, order part number and size as shown on parts list.
(488 - Mack Truck Yellow) When ordering parts if color or finish is important, use color code
(497 - Yard-Man Red) Shown at left (e.g. Mack Truck Yellow Finish - 14542 (488).)
The engine is not under warranty by the leaf blower manufacturer. If repairs or service is needed on the
engine, please contact your nearest authorized engine service outlet. Check the "Yellow Pages" of your
telephone book under "Engines - Gasoline".
