AIR FLOW FOR INDICATED AIR TEMPERATURE RISE=*
TEMP RISE °F
70
75
80
85
90
95
100
AIR FLOW CFM
795
741
695
654
618
585
556
*At Rated Input
Optional External Filter Rack
Mounts on Either Side
ACCESS
AIR DELIVERY PERFORMANCE!
Air
Delivery
CFM
EXTERNAL STATIC PRESSURE AVAILABLE
Type L or M Motor
Type E Motor
Hi
Med
Med-Lo
Lo
Hi
Med
Med-Lo
Lo
500
.88
.78
.70
.58
.77
600
.76
.65
.52
.06
.61
700
.63
.47
.78
.27
800
.48
.60
900
.16
.74
.33
1000
.76
.58
1100
.63
.38
1200
.46
.14
1300
.27
1400
.07
Above data gives Cfm •under •typical field applications (i.e. 125 volts).
LINE-TO-LINE SCHEMATIC
UNIT WIRING DIAGRAMS
PDS 394U.80.2
