Bolens 19200 User Manual
Three point hitch parts list, Moderi9200
Attention! The text in this document has been recognized automatically. To view the original document, you can use the "Original mode".

Moderi9200
Serial Numbers 0100101 thru
0299999
Three Point Hitch
Parts List
30
REF.
NO.
PART
NO.
DESCRIPTION
NO.
REQ'D.
REF.
NO.
PART
NO.
DESCRIPTION
NO.
REQ'D.
1
1723478
Spring Cotter ........ ..........
5
18
1724786
Stud, R.H. ............................
2
2
1724640
Clevis Pin.
2
19
1185256
Drive Pin ...................... . .'.
4
3 . 1724797
Adjusting Link Assembly
20
1724793
Adjusting Link Assembly
(Incl. Ref. Nos. 4,5 & 6) ,
■ 1'
(incl. Ref. Nos. 18, 19 .
4
1185340
Drive Pin, 1/4 X 3 / 4 . . . . . .
2
&2V . . .
. . ..... ..............
2
■ . 5
1719578
Stud, R.H. . . . . . . . . . . .
1
2 1
1724785
Stud, L.H. ............................
2
■ 6.
1719579
Stud, L.H. .......... .. ............
1
22
1719349
: Retaining Pin .............
Z
7 • 1103251
Capscrew, 1/2-13x1 . . . .
. 2
2 3
1186425 .
Ciev's Pin...................
2
8 • 1100245
Lockwasher, 1 /2 . . . . . . .
2
2 4
1718773
Clevis Pin, 3/4,X 2-3/4 . . . .
2
9
1731553
Hitch Bracket.................... . 1
25
1185590
Hitch Pin.....................
2
10
1724639
Clevis Pin......... . . . .
1
2 6 •
1110107
Hex Nut, 5/8-11..............
2
11 •
1107386
Flat Washer, 5/8 . . . . . . . . 2
’ 2 7
1107382
Flat Washer, 5/8........... . . .
2
■'12 -•
1186235
Hex Nut, 5/8-11. .
. 4
28
1715525
Pivot......................................
'2
13
1103283
Capscrew, 5/8-11 x 2-1/2 .
4
29
1725434
Chain Assembly . . . . . . . .
2
1 4
1725430
Spacer. . . . . . . . . . . . . .
4
3 0
‘ 1725433
Link Lower Assembly . . . .
2
15
1100758
Grease Fitting. ..................
2
31
1725440
Bar Sway Assembly......... ..
1
16
1724710 ' Bearing B l o c k . . . . . . . . . . 2
3 2 ,
.1727033
Fender Trim. .......................
1
17
1725429
Pivot Shaft Assembly....
1
' T ■ . ' ■ . '
E
6
FORM NO. P-552657-1 (11/78)
• Common Hardware ■Purchase Locally (Grade 5 Where Applicable)
Supersedes P552657
........ .
... . ...
...... ■ • '
. - ■---■. .'
- ...
........... .......
