Altec Lansing 8000 Series - Manual (Page 2)

8000 SERIES LOUDSPEAKER SYSTEMS
SPECIFICATIONS
8124 8127 8227' 8154 8156 8256' 8184 8182
Type: vented vented vented vented vented vented vented vented
Speakers
Included 3124 3127 3127 (2) 3154 3156 3156 (2) 3184 3182
Sensitivity
in dB SPL—'
4 feet: 91 95 98 93 98 100 96 91
1 meter: 93 97 100 95 100 102 98 93
Maximum SPL
4 feet
112.5 117 122 115 119 122 117 113
1 meter 114 119 124 117 121
124 119 115
Internal
Volume: 3 ft' 1.5 ft' 3 ft' 6 ft' 3 ft' 6 ft' 12 ft' 24 ft'
Tuning (FB): 38 Hz 77 Hz 77 Hz 32 Hz 57 Hz 57 Hz 39 Hz 20 Hz
F 3 : 40 Hz 70 Hz 70 Hz 40 Hz 65 Hz 65 Hz 40 Hz 23 Hz
Construction': 7-ply 7-ply 7-ply 7-ply 7-ply 7-ply 7-ply 7-ply
Finish"': gray gray gray gray gray gray gray gray
Dimensions—
Height: 30" 19" 30" 36" 30" 36" 36" 54"
76.2 cm 48.3 cm 76.2 cm 91.4 cm 76.2 cm 91.4 cm 91.4 cm 137.2 cm
Width: 19" 16" 19" 30" . 19" 30" 30" 36"
48.3 cm 40.6 cm 48.3 cm 76.2 cm 48.3 cm 76.2 cm 76.2 cm 91.4 cm
Depth: 143 / 4 " 143 / 4 " 143 / 4 " 143 / 4 " ' 143 / 4 " 143 / 4 " 26V4" 26V4"
37.5 cm 37.5 cm 37.5 cm 37.5 cm 37.5 cm 37.5 cm 66.7 cm 66.7 cm
Weight: 60.5 lbs 42 lbs 78 lbs 90 lbs 61.5 lbs 106 lbs 124 lbs 170 lbs
27.5 kg 19 kg 35 kg 41 kg 28 kg 48 kg 56 kg 77 kg
' Dual loudspeaker system. Sensitivity and maximum SPL includes 3 dB gain due to loudspeaker coupling.
^ Measured with 1 watt (E x I) input of band-limited pink noise from 100 Hz to 1 kHz at 1 meter.
^ 7-ply birch face plywood. Acoustically braced on all sides, except for small 1.5-cubic foot unit.
Incident sides lined with fiberglass except for Model 8182.
Mar (scuff) resistant textured gray spatter for high durability.
The response and impedance of each system are published with the specifications for the 3000-series loudspeaker used
in the system.
AL^"EIC
LAISISirsIG
P.O. BOX 26105, OKLAHOMA CITY, OK 73126-0105, U.S.A.
©1989 ALTEC LANSING CORPORATION
PRINTED IN U.S.A. 6/89 — 2M Revision 5 AL-2527
42-07-027090
