Assembly Instructions for
Chair No. DC724
PART LIST
KEY QTY
DESCRIPTION
KEY QTY
DESCRIPTION
KEY QTY
DESCRIPTION
1
5
Ca3ters
7
1
Backrest
12
4
Seat Plate Screws
2
1
Base
8
1
Lumbar Support Strap
13
1
Footrest + Height
3
1
Gas Cylinder
9
1
Seat Depth Adjustment
Adjustment Knob
4
1
Cylinder Cover
Knob + Washers
14
1
Extension Tube
5
1
Seat Piate
10
2
Armrests
6
1
Seat
11
6
Armrest Screws
