English
9
CZ209
Sound Adjustment
Sound effects and tone can be adjusted as
desired.
● Setting the Z-Enhancer Plus
This unit has 4 sound tone effects stored in
memory.
Select the effect you prefer.
∗
The factory default setting is “OFF”.
2-1. Select “Z-EHCR+”.
3-1. When you turn the [ROTARY] knob, the
tone effect changes as follows:
“OFF” ↔ “B-BOOST” ↔ “IMPACT” ↔
“EXCITE” ↔ “CUSTOM”
OFF : No sound effect
B-BOOST : Enhanced bass
IMPACT : Enhanced bass and treble
EXCITE : Enhanced bass, mid, and
treble
CUSTOM : User customized
When set to “B-BOOST/IMPACT/EXCITE”:
3-2. Press the [ ] button.
3-3. Turn the [ROTARY] knob to adjust the
setting (Setting range: – 3 to +3).
∗
The factory default setting is “0”.
3-4. Press the [ ] button to return to the
previous mode.
When set to “CUSTOM”:
3-2. Press and hold the [ ] button (1 sec.).
Bass/treble characteristics become flat and
“FLAT” is show in the display.
3-3. Turn the [ROTARY] knob to change to the
“OFF” mode.
● Adjusting the bass
This adjustment is supported only when
Z-Enhancer Plus is set to “CUSTOM”.
2-1. Select “BASS”.
3-1. Press the [ ] button.
3-2. Press [x] or [v] to change and select
settings as follows:
“B” ↔ “B” ↔ “Q 1”
3-3. Turn the [ROTARY] knob to adjust values
for gain, F (center frequency) and Q curve.
B :The factory default setting is “0”.
(Adjustment range: + 7 to – 7)
B :The factory default setting is
“60”.
(Adjustment range:
60/80/100/200)
Q 1 :The factory default setting is “1”.
(Adjustment range: 1/1.25/1.5/2)
3-4. Press the [ ] button to return to the
previous mode.
● Adjusting the treble
This adjustment is supported only when
Z-Enhancer Plus is set to “CUSTOM”.
2-1. Select “TREBLE”.
3-1. Press the [ ] button.
3-2. Press [x] or [v] to change and select
settings as follows:
“T” ↔ “T”
3-3. Turn the [ROTARY] knob to adjust values
for gain and F (center frequency).
T : The factory default setting is “0”.
(Adjustment range: +7 to – 7)
T : The factory default setting is
“10K”.
(Adjustment range: 10K/12.5K/
15K/17.5K)
3-4. Press the [ ] button to return to the
previous mode.
To change sound settings
1. Press the [SOUND] button to switch to the
sound adjustment display.
∗
The factory default sound setting is “Z-
EHCR+
”.
2. Press [x] or [v] to select the sound
adjustment mode.
Each time [x] or [v] is pressed, the
sound adjustment mode changes as
follows:
“Z-EHCR+” ↔ “BASS” ↔ “TREBLE” ↔
“BALANCE” ↔ “FADER” ↔ “NF VOL”
∗
When “ENT” is flashing in the display, press
the
[ ] button to adjust the setting value.
∗
The sound adjustment mode is displayed
for 2 seconds before showing the sound
setting.
3. Turn the [ROTARY] knob to adjust the
selected audio mode.
4. After completing settings, press the
[SOUND] button to return to the previous
mode.
