The
COML 2232F card is an isolated dual-port RS-232 CompactFlash serial card with the
following features:
Type II CompactFlash form factor for CF+ equipped PDAs, Handheld PCs,
laptops, etc.
SeaCOM software provided for Windows 95, 98, 98SE, Me, 2000, and XP
Drivers not required for Windows CE and PocketPC
16C550 compatible, buffered UART with 16-byte FIFO
RS-232 interfaces are isolated up to +/-50 VDC relative to local host ground.
Data rates to 115.2K bps
3.3V compatible
All modem control signal signals implemented
Compatible with all standard serial COM software
Software controlled power management
Low power consumption
Detachable 12” cable with two DB-9M connectors
