12 A419 Series Electronic Temperature Controls with Display and NEMA 1 or NEMA 4X Watertight Enclosures
Product/Technical Bulletin

Technical Specifications

Product A419 Series Electronic Temperature Controls with NEMA 1 General Purpose or NEMA 4X

Watertight, Corrosion-Resistant Enclosures

Setpoint Range -30 to 212°F (-34 to 100°C)

Differential Range 1 to 30F° (1 to 30C°)

Supply Voltage 24 VAC, 60 Hz, Class 2:

A419GBF-1 (NEMA 1 Enclosure Model)

A419GEF-1 (NEMA 4X Watertight Enclosure Model)

120 or 240 VAC, 60 Hz:

A419ABC-1 (NEMA 1 Enclosure Model)

A419AEC-1 (NEMA 4X Watertight Enclosure Model)

Power Consumption 1.8 VA Maximum

Output Relay Contacts

Electrical Ratings

24 VAC Models:

A419GBF-1 (NEMA 1 Enclosure)

A419GEF-1 (NEMA 4X Watertight Enclosure)

100 VA, 30 VAC maximum, Class 2

120/240 VAC Models:

A419ABC-1 (NEMA 1 Enclosure)

A419AEC-1 (NEMA 4X Watertight Enclosure)

Applied Voltage:

120 VAC

208 VAC

240 VAC

Horsepower N.O. (N.C.) :

1 (0.25) hp

1 (0.33) hp

1 (0.5) hp

Full Load Amperes N.O. (N.C.):

16 (5.8) A

9.2 (4.0) A

8.0 (4.9) A

Locked Rotor Amperes N.O. (N.C.):

96 (34.8) A

55.2 (24) A

48 (29.4) A

Non-inductive Amperes N.O. (N.C.):

15 (10) A

10 (10) A

Pilot Duty:

125 VA (N.O. contacts) at 24 to 240 VAC

125 VA (N.C. contacts) at 120 to 240 VAC

50 VA (N.C. contacts) at 24 VAC

Sensor Type A99BB Type PTC Sensor (See Table 6)

Control Ambient

Temperature

Operating:

-26 to 140°F (-32 to 60°C)

Shipping:

-40 to 185°F (-40 to 85°C)

Ambient Humidity 0 to 95% RH Non-condensing; Maximum Dew Point: 85°F (29°C)

Control Material Case and Cover:

NEMA 1 High-Impact Thermoplastic

NEMA 4X Watertight, Corrosion-Resistant, High-Impact

Thermoplastic Polycarbonate

Agency Listings UL: File E27734; CCN’s XAPX (US), XAPX7 (Canada)

FCC: CFR 47, Part 15, Class A. DOC, Class A
