12-1263-02 11
ADD2 Product Specifications 1
MODEL
RATINGS2
1st Stage Input BTUH
1st Stage Capacity BTUH (ICS)3
2nd Stage Input BTUH
2nd Stage Capacity BTUH (ICS)3
AFUE (ICS)
Temp. Rise (Min.-Max.) °F.
BLOWER DRIVE
Dia.-Width (In.)
No. Used
Speeds (No.)
CFM vs. in. w.g.
Motor HP
R.P.M.
Volts/Ph/Hz
COMBUSTION FAN — TYPE
Drive - No. Speeds
Motor HP - RPM
Volts/Ph/Hz
FL Amps
FILTER — Furnished?
Type Recommended
Filter (No.-Size-Thk.)
VENT — Size (In.)
HEAT EXCHANGER
Type -Fired
-Unfired
Gauge (Fired)
ORIFICES — Main
Nat. Gas. Qty. — Drill Size
L.P. Gas Qty. — Drill Size
GAS VALVE
DIRECT IGNITION DEVICE
Type
BURNERS — Type
Number
POWER CONN. — V/Ph/Hz4
Ampacity (In Amps)
Max. Overcurrent Protection (Amps)
PIPE CONN. SIZE (IN.)
DUCT CONN.
DIMENSIONS
Crated (In.)
Uncrated
WEIGHT
Shipping (Lbs.)/Net (Lbs.)
ADD2C100A9602A
65000
52000
100000
80000
80.0
30 - 60
DIRECT
11 x 10
1
4
SEE FAN PERF. TABLE
1/2
1075
115/1/60
CENTRIFUGAL
DIRECT - 2
1/50 - 3000
115/1/60
0.93
YES
HIGH VELOCITY
2 - 16 X 20 - 1 IN
4 ROUND
ALUMINIZED STEEL TYPE 1
20
5 - 45
5 - 56
REDUNDANT - TWO STAGE
HOT SURFACE IGNITOR
IN-SHOT
5
115/1/60
12.8
15
1/2
SEE OUTLINE DRAWING
H X W X D
41-3/4 X 23 X 30-1/2
SEE OUTLINE DRAWING
167 / 155
ADD2D120A9602A
78000
62400
120000
95000
80.0
30 - 60
DIRECT
11 x 10
1
4
SEE FAN PERF. TABLE
3/4
1075
115/1/60
CENTRIFUGAL
DIRECT - 2
1/50 - 3000
115/1/60
.95
YES
HIGH VELOCITY
2 - 16 X 20 - 1 IN
4 ROUND
ALUMINIZED STEEL TYPE 1
20
6 - 45
6 - 56
REDUNDANT - TWO STAGE
HOT SURFACE
IN-SHOT
6
115/1/60
12.8
15
1/2
SEE OUTLINE DRAWING
H X W X D
41-3/4 X 26-1/2 X 30-1/2
SEE OUTLINE DRAWING
186/174
ADD2D140A9602A
91000
72800
140000
112000
80.0
45 - 75
DIRECT
11 x 10
1
4
SEE FAN PERF. TABLE
3/4
1075
115/1/60
CENTRIFUGAL
DIRECT - 2
1/50 - 3000
115/1/60
.95
YES
HIGH VELOCITY
2 - 16 X 20 - 1 IN
4 ROUND
ALUMINIZED STEEL TYPE 1
20
7 - 45
7 - 56
REDUNDANT - TWO STAGE
HOT SURFACE
IN-SHOT
7
115/1/60
13.1
15
1/2
SEE OUTLINE DRAWING
H X W X D
41 X 25-1/2 X 29-1/2
SEE OUTLINE DRAWING
197 / 184
1 Central Furnace heating designs are certified by AGA and ETL.
2 For U.S. applications, above input ratings (BTUH) are up to 2,000 feet, derate 4% per 1,000 feet for elevations above 2,000 feet above sea level. For Canadian
applications, above input ratings (BTUH) are up to 4,500 feet, derate 4% per 1,000 feet for elevations above 4,500 feet above sea level.
3 Based on U.S. government standard tests.
4 The above wiring specifications are in accordance with National Electrical Code; however, installations must comply with local codes.
