Inch deck changing the transmission drive belt – Troy-Bilt Pony User Manual
Page 23
3
s
ectiOn
7 — s
ervice
3
s
ectiOn
7 — s
ervice
Remove the deck belt from around all pulleys, including
the deck idler pulley.
Route the new belt as shown in Fig. 7-7.
Remount the belt guards removed earlier.
5.
6.
7.
Figure -
Deck Idler Pulleys
Engine Pulley
Idler Bracket
42-Inch Deck
Changing the Transmission Drive Belt
NOTE: Several components must be removed and special tools
(i.e. air/impact wrench) in order to change the tractor’s drive belt.
See an authorized Troybilt Service Dealer to have your drive belt
replaced or phone Customer Support as instructed on page 2 for
information on ordering a Service Manual.
