Models 604R, 614R, 626R, 628R, 636R and 638R
NOTE: The engine is not under warranty by
the mower manufacturer. . . I f repairs or
service is needed on the engine, please
contact your nearest author
ized engine service outlet.
Check the “Yellow Pages” of
your
telephone
book
under
“Engines—Gasoline.”
Find It Fast
In The
Yellow Pages
“N
PARTS LIST FOR MODELS 604R, 614R, 626R, 628R, 636R AND 638R LAWN MOWERS
REF.
NO.
PART
NO.
CODE
DESCRIPTION
REF.
NO.
PART
NO.
CODE
DESCRIPTION
1
710-0255
Truss Mach. Scr. V4-20 x .75"
11 17521
N
Front Axle Ass’y-
Lg-
12 17800
N
Axle Mounting Plate
2
736-0329
L-Wash. V4" I.D.*
13 710-0969
Truss Mach. Hi-Riser Tap Scr.
3
720-0236
N
Plastic Knob
#12
X
1" Lg.
4
732-0675
N
Ball Plunger
14 736-0105
Bell-Wash. .38" I.D. x .88"
5
738-0137
Shid. Bolt .342" Dia. x .268" Lg.
15 738-0102
ShId. Bolt .498" Dia. x 1.45"
6
738-0811
N
Height Adjuster Spindle
16 734-1670
N
Front Wheel Ass’y- Comp.
7
731-1128
N
Spindle Guide
17 731-0981A
Hub Cap
8
747-0590
N
Height Adjustment Rodf
18 17802
Height Adj. Spindle Brkt.
747-0589
N
Height Adjustment Rodft
19 710-0969
Truss Mach. Hi-Riser Tap Scr.
9
747-0803
N
Height Adjustment Linkf
#12
X
1" Lg. (604R, 614R)
747-0802
N
Height Adjustment Linktt
20 710-0603
Hex B-Tap 5/16-18 x .5" Lg.
10
714-0104
Int. Cotter Pin 5/16" Dia.
(626R, 628R, 636R, 638R)
(604R, 614R)
21 741-0180
Ball Bearing
714-0507
Cotter Pin 3/32" Dia. (626R,
22 736-0232
Wave Wash. .53" I.D.
628R, 636R, 638R)
23 736-0326
FI-Wash. .51" I.D. x 1" O.D.
tModels 614R, 636R and 638R Only.
ttModels 604R, 626R and 628R Only.
