PARTS LIST FOR MODEL NOS. 112-300, 112-305, 112-310 and 112-315
REF.
NO.
112-300
PART NO.
112-305
PART NO.
112-310
PART NO.
112-315
PART NO.
DESCRIPTION
1
11597
11597
11597
11597
Throttle Control — complete
2
None
710-437
None
710-437
Round Hd.Mach.Scr. 10—24xy2” Ig. *
3
None
11604
None
11604
Handle Panel
4
305-7470
305-7470
305-7470
305-7470
Throttle Control — Knob
5
11600
11600
11600
11600
Throttle Control — Bracket Assembly
6
732-141
732-141
732-141
732-141
Conduit and Wire
7
—
—
—
—
Engine
8
710-158
710-158
710-158
710-158
Hex Hd.Cap Scr. 5/16—24x1%” Ig. *
9
11144
11144
11145
11145
Hinge Rod
io
726-106
726-106
726-106
736-106
Push-on Flange Palnut
11
11445
11445
11446
11446
Deck Assembly
12
None
10950
None
10950
Height Adjuster Assembly Complete — L.H.
13
504-9392
504-9392
505-9392
505-9392
Wheel Assembly — complete
14
10769
10769
10769
10769
Blade Adapter Kit
15
711-555
711-555
711-555
711-555
Pivot Pin
16
714-365
714-365
714-365
714-365
Key Hi Pro #505
17
748-189
748-189
748-189
748-189
Blade Adapter
18
742-123
742-123
742-125
748-125
Blade
19
736-217
736-217
736-217
736-217
Spring Lockwasher 3/8 Scr. — Heavy duty
20
710-459
' 710-459
710-459
710-459
Hex Hd.Cap Scr. 3/8-24xP/
2
” Lg. H.T.
21
710-117
710-117
710-117
710-117
Hex Hd. Cap Scr. 5/16—24x 1” Lg. H. T.
22
736-119
736-119
736-119
736-119
Spring Lockwasher 5/16” Screw *
23
712-123
712-123
712-123
712-123
Hex Nut 5/16—24 Thread *
24
11130
11130
11130
11130
Adapter Plate
25
None
10951
None
10951
Height Adjuster Assembly — complete — R.H.
26
736-105
736-105
736-105
736-105
Belleville Washer
27
305-7006
305-7006
305-7006
305-7006
Portiflex Bearing
28
738-213
738-102
738-213
738-102
Axle Bolt
29
11141
11141
11141
11141
Chute Deflector
30
732-253
732-253
732-253
732-253
Torsion Spring
31
None
710-209
None
710-209
SEMS Hex. Hd.Cap Scr. 3/8-16x5/8” Lg.
32
714-507
714-507
714-507
714-507
Cotter Pin 3/32” dia.
X
3/4” Lg. *
33
11161
11161
11167
11167
Protective Shield
34
712-107
712-107
712-107
712-107
Hex Center Locknut %—20 Thread
35
310-7016
310-7016
310-7036
310-7036
Lower Handle
36
710-106
710-106
710-106
710-106
Hex Hd. Cap Screw %—20x 1%” Lg. *
37
310-9364
310-9364
310-9364
310-9364
Upper Handle (2 Required)
38
710-606
710-606
710-606
710-606
Hex Hd.Cap Screw %—20x 1%” Lg. *
39
305-7071
305-7071
305-7071
305-7071
Grip
40
710-148
None
710-148
None
Self Tap Screw #8-32x5/16” Lg. *
41
11608
None
11608
None
Plastic Cover
42
None
712-526
None
712-526
Speed Nut
43
None
305-7520
None
305-7520
Spring Lever — Knob
44
None
10949
None
10949
Spring Lever Assembly with Knob
45
None
736-219
None
736-219
Spring Washer
46
None
712-116
None
712-116
Elastic Locknut 3/8—24 Thread
47
None
10937
None
10937
Pivot Bar
48
None
10934
None
10934
Index Plate Assembly — R.H.
None
10935
None
10935
Index Plate Assembly — L.H.
49
746-145
746-145
746-145
746-145
Cable Clip
*For faster service, obtain standard nuts, bolts and washers locally. If these items caimot be obtained locally, order by
part number and size as shown on the parts list.
(349 Cypress Green) When ordering parts if color or finish is important, use the appropriate color code shown at left.
(414 Tiara Gold) (e.g. Cypress Green finish — 11445 (349).
NOTE: This instruction manual covers various models and all accessories shown do
not necessarily apply to your model mower.
The engine is not under warranty by the mower manufacturer. If repairs or service is
needed on the engine, please contact your nearest authorized engine service outlet.
Check the “Yellow Pages” of your telephone book under “Engines - Gasoline.”
