Model 035
REF.
NO.
PART
NO.
CODE
DESCRIPTION
REF.
NO.
PART
NO.
CODE
DESCRIPTION
1
686-0085
N
Chain Case Ass’y-—R H.
23
713-0216
Chain #35 .375" Pitch 50 Links
2
611-0057
N
Input Shaft Ass’y-
713-0139
#35 Master Link
3
04757
Hub and Sprocket Ass’/.
25
05034A
Bearing Housing
4
750-0351
Bearing Inner Race
27
741-0228
Bearing
5
741-0155
Ball Bearing
28
731-0486
Dust Captt
6
686-0087
N
Chain Case Ass’y.—L. H.
29
710-0599
Hex Wash. Hd. Self-Tap
7
756-0996
N
Pulley—Chain Caseft
Scr. 1/4-20
X
.50" Lg.
8
710-0369
Hex Bolt 3/8-24 x 2.5"*
30
750-0471
Spacer .63" I.D. x .77"
10
721-0157
Sealft
O.D.
X
.38" Lg.
11
710-0195
Hex Bolt 1/4-28
X
.625”*
32
750-0999
N
Spacer .647 x .77"tt
12
721-0156A
Gasket
33
710-0653
Hex Wash. Hd. Self-Tap
13
741-0227
Flange Brg. .879" I.D.
Scr. 1/4-20
X
.38" Lg.
14
736-0265
FI-Wash. .88" I.D. x 1.5"
34
710-0118
Hex Bolt 5/16-18
X
.75" Lg.*
15
04920
Tine Shaft Ass’y.
35
712-0267
Hex Nut 5/16-18 Thd.*
16
750-0354A
Spacer 7/8" I.D.
36
736-0119
L-Wash. 5/16" I.D.*
17
736-0329
L-Wash. 1/4" I.D.*
37
736-0105
Bell-Wash. .38" I.D. x .88" O.D.
18
712-0138
Hex Nut 1/4-28 Thd.*
38
712-0379
Hex Flange L-Nut 3/8-24 Thd.
19
712-0116
Hex Ins. L-Nut 3/8-24 Ihd.
—
686-0093
N
Chain Case Ass’y. Comp.
21
736-0219
Bell-Wash. .406" I.D.
22
713-0215
Chain #420 1/2" Pitch i 8 Links
713-0154
#420 Master Link
tfNot part of chain case assembly.
6A — Page 4
