RYOBI FIXED BASE ROUTER - MODEL NUMBER R163
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your ROUTER MOTOR or when ordering repair parts.
PARTS LIST FOR SECTION “A”
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 660133010 * Screw (8-18 x 24 Pan Hd.) ............................................. ............ 4
2 660929001 * Screw (M3.5 x 14.5 Pan Hd.).......................................... ............ 1
3 200557001 Router Base/Spindle Lock Actuator Kit
(Included With Key 13 On Pages 2-3).......................... ............ 1
4 672090001 Torsion Spring ............................................................. ............ 1
5 514543001 Bearing Frame.............................................................. ............ 1
6 680769003 Ball Bearing (6003)....................................................... ............ 1
7 660299021 * Screw (M5 x 13 mm Wafer Hd.)...................................... ............ 2
8 290138021 LED Work Light Assembly............................................ ............ 1
9 514412001 Motor Housing.............................................................. ............ 1
10 760676001 On/Off Switch ............................................................... ............ 1
11 290086037 Power Cord Assembly.................................................. ............ 1
12 5950101 Cord Clamp................................................................... ............ 1
13 6620805 * Screw (M4 x 16 mm Pan Hd.) ........................................ ............ 6
14 514413001 Top Bearing Bracket..................................................... ............ 1
15 660103001 * Screw (M0.17 x 3/4 in. Pan Hd.)..................................... ............ 4
16 280013103 Circuit Board Assembly................................................ ............ 1
17 660182003 * Screw (6-19 x 5/16 in. Pan Hd.) ..................................... ............ 1
18 200452001 Upper Cap Assembly (Inc. Key Nos. 30 and 31)......... ............ 1
19 290286001 LED Work Light & Frame (Inc. key Nos. 5 and 8)........ ............ 1
20 690190002 Collet Nut ..................................................................... ............ 1
21 671399001 Retaining Ring ............................................................. ............ 1
22 740894001 Armature....................................................................... ............ 1
23 290069107 Brush Assembly ........................................................... ............ 2
24 630801001 Brush Tube Clamp........................................................ ............ 2
25 660138001 * Screw (8-16 x 1/2 in. Pan Hd.) ....................................... ............ 2
26 680966001 Ball Bearing (CW 608RS)............................................. ............ 1
27 660928001 * Screw (M4.3 x 56)........................................................... ............ 2
28 740895001 Field.............................................................................. ............ 1
29 514266001 Chip............................................................................... ............ 1
30 940054128 Logo Label.................................................................... ............ 1
31 940077080 Data Label.................................................................... ............ 1
32 940999110 Cord Label.................................................................... ............ 1
33 671250001 Wrench.......................................................................... ............ 1
* STANDARD HARDWARE ITEM - MAY BE PURCHASED LOCALLY
NOTE: The assembly shown represents an important part of the double insulated system. To avoid
the possibility of alteration or damage to the system, service should be performed by your nearest
authorized service center.
