MODELS 643C, 643B & 645A
REF
NO.
PART NO.
DESCRIPTION
REF
NO.
PART NO.
DESCRIPTION
1
686-04043
Tine Flood Assembly
(A)
27
732-04185
Spring, Forward Clutch
686-04041
Tine Flood Assembly
(B) (C)
28
746-04208
Cable Assembly, Forward Clutch
2
710-0395
Hex Screw, 5/16-18x2.25
29
746-04058
Cable Assembly, Reverse Clutch
(B) (C)
3
710-0597
Hex Hd. Screw, 1/4-20 x 1
30
747-04210
Bail, Forward Clutch
4
710-0599
Screw, Self-Tapping,1/4-20 x 1/2
31
749-04084
Upper Handlebar
5
710-0874
Hex Hd. Screw, 5/16-18x1-1/4
32
749-04208
Lower Handlebar
6
710-3008
Hex Hd. Screw, 5/16-18x .75
33
749-04106
Tab, Conduit Mount
7
712-04063
Hex Lock Nut, Nylon, 5/16-18
34
732-04040
Bracket, Reverse Clutch Cable
(B) (C)
8
712-04064
Hex Lock Nut, Nylon, 1/4-20
35
786-04188
Handlebar Support
9
715-0108
Spirol Pin
36
786-04200
Panel
10
732-04320
Spring, Depth Regulator
37
710-0216
Screw, Hex, 3/8-16 x 3/4
11
736-0275
Flat Washer, 5/16
38
710-0805
Screw, Hex, 5/16-18x1-1/2
12
750-04149
Spacer, .462X,328x1.63
39
712-3000
Hex Lock Nut, 3/8-16
13
750-04160
Bushing
40
736-0119
Lock Washer, 5/16
14
750-04556
Spacer
41
725-0157
Cable Tie
15
786-04092
Reverse Stop Arm
42
736-3050
Flat Washer, 3/8
16
786-04098
Channel Support Bracket
43
712-04065
Flange Lock Nut 3/8-16
17
786-04104
Drag Bar
44
710-0347
Hex Hd, Screw, 3/8-16x1-3/4
18
786-04191
Flap Stop Bracket
45
710-0514
Hex Hd. Screw, 3/8-16x1, Grade 5
19
786-04290
Hood Bracket, Left Hand
46
710-04048
Flange Screw ,312-18x 1.00
20
786-04291
Hood Bracket, Right Hand
47
742-04117
Single BoloTine - Left Hand
21
786-04292
Adjustable Depth Bar
48
742-04116
Single Bolo Tine - Right Hand
22
710-0106
Hex Hd. Screw, 1/4-20x1-1/4
49
686-04066
Tine Holder
(A)
23
710-04163
Screw, #10-24x2
686-04065
Tine Holder
(B) (C)
24
712-3009
Hex Lock Nut, 5/16-18
GW-1901
Bolo Tine Replacement Set
(Incl. eight
25
712-0121
Hex Nut, #10-24
right-hand tines, eight left-hand tines and
26
712-0291
Hex Lock Nut, 1/4-20
required hardware).
(A) (B) (C)
(A)
For Model 643C
(B)
For Model 643B
(C)
For Model 645A
