PARTS LIST FOR MOWER MODEL 110-065-002
Ref.
No.
Part
No.
DESCRIPTION
1 —
Engine
2 710-158 Hex Head Cap Screw 5/16- 24 x 1-1/4 Lg. *
3 712-123 Hex Nut 5/16 — 24 thread *
4 736-119 Spring Lockwasher 5/16 Screw *
5 387-9650 Deck Assembly
6 387-9790 Front Extension Bracket Assembly
7 712-107 Hex Nut 1/4 — 20 thread *
8 736-498 Internal Lockwasher 1/4 Screw *
9 711-242 Spacer
10 310-7492 \^eel Pivot Bar — Front
11 714-365 Key - Hi Pro #505
12 748-100 Blade Adapter
13 312-7582 Blade
14 312-7919 Anti-Scalp Plate
15 736-169 Spring Lockwasher 3/8 Screw *
16 710-113 Hex Head Cap Screw 3/8-24 x 1-5/8 Lg. — Heat Treated
17 710-117 Hex Head Cap Screw 5/16—24 x 1 Lg. — Heat Treated
18 310-8494 Hub Cap
19 738-102 Axle Bolt - Front Wheel
20 305-7006 Fortiflex Bearing
21 502-9392 Wheel Assembly — Front
22 736-105 Belleville Washer
23 710-191 Hex Head Cap Screw 3/8—24 x 1-1/4 Lg. *
24 310-9008 Spring Lever Assembly
25 305-7520 IGiob
26 710-289 Hex Head Cap Screw 1/4—20 X 1/2 Lg. *
27 710-233 Weld Pin
28 394-9664 Rear Wheel Bracket — Right Hand
29 394-9665 Rear Wheel Bracket — Left Hand
30 714-104 Hairpin - Cotter *
31 712-214 Gripco Locknut 3/8 — 24 tliread *
32 712-207 Speed Nut
33 712-208 Speed Nut
34 710-192 Truss Head Machine Screw 10—24 x 3/8 Lg. *
35 310-9668 Wheel Pivot Bar — Rear
36 394-9675 Rear Cover
37 738-213 Axle Bolt - Rear Wheel
38 310-8398 Handle Lower
39 387-7857 Handle Panel
40 310-9364 Handle Upper
41 305-7071 Handle Grip
42 310-9278 Exhaust Deflector
43 710-315 Hex Head Thread Cutting Screw Type “F” #8 x 5/8 Lg. *
45 310-8511 Throttle Control Complete
46 305-7470 Knob
47 310-8506 Throttle Control Bracket t
48 901-7627 Ferrule Assembly t
49 732-141 Conduit and Wire t
50 710-407 Slot Hex Head Ex. Screw #8—32 x 1/2 Lg.
51 712-107 Hex Centerlock Nut 1/4-20 thread *
52 712-526 Speed Nut
53 710-106 Hex Head Cap Screw 1/4-20 x 1-1/4 Lg. *
54 710-606 Hex Head Cap Screw 1/4-20 x 1-1/2 Lg. *
55 746-145 Cable Clip (not shown)
56 501-9392 Wheel Assembly — Rear
57 387-9961 Engine Shroud
58 710-138 Round Head Machine Screw 10—24 x 1/4 Lg.
* For faster service order standard nuts, bolts, and washers locally. If these items cannot be obtained locally,
order by part number and size as shown on parts list.
t Part of Throttle Control Complete 310-8511
FORM NO. 770-2796 C
