Titan/cPCI User’s Manual, Connect Tech Inc.
6 Revision 1.01
Figure 4: Titan/cPCI Rear I/O two and four port adapters
J1
J2
J4
Titan/cPCI Rear I/O
2 port model
J1
J2
J3
Ejector
Handle
DB-37
Connector
Ejector
Handle
Rear I/O
Connector
Rear I/O
Connector
DB-9
Connector
Port 2
DB-9
Connector
Port 1
Titan/cPCI Rear I/O
4 port model
Jumper J1
+5/+12V Select
Jumper J2
DSR/Power Select (Ports 1 & 2)
Jumper J3
DSR/Power Select (Ports 3 & 4)
Jumper J4
Direct GND
J4
Jumper J1
+5/+12V Select
Jumper J2
DSR/Power Select (Ports 1 & 2)
Jumper J4
Direct GND
