Clarity W1000 comes assembled with
mounting bracket attached in desk mount
position. For wall mounting simply remove
bracket, rotate 180
° and reattach as
shown.
To Install As a Wall Unit:
Important: A modular wall jack with raised
mounting pins is required for installation as
a Wall Unit.
• Plug one end of the telephone line cord
(long, flat) into the back of the Clarity
telephone.
Desk
Mount
key
Wall
Mount
Key
INSTALLATION
Back of
Phone
Wall
Mount
Bracket
• Attach the wall-mounting bracket to the
bottom of the Clarity telephone. It snaps
into place. The cord should run under-
neath the wall mounting bracket.
• Plug the other end of the telephone line
cord into the wall jack with raised mount-
ing pins. You can store excess line cord
inside the wall mounting bracket.
Note: If the wall-mounting bracket is
already placed in the desk mount
position, remove it by pressing the tabs
and turning it 180
° per the key shown
for the wall-mount.
