SPECIFICATION
LCD Panel
Driving system TFT Color LCD
Size 24'W(61cm)
Pixel pitch 0.276mm(H) x 0.276mm(V)
Brightness 250cd/m^(Typical)
Contrast 100,000,000:1 Max. (ACM)
Viewable angle 170“ (H)160"(V)(CR=10)
Response time Sms (on/off)
Panel Type TN
Video R, G, B Analog Interface
H-Frequency 30KHZ-80KHZ
V-Frequency 55-75HZ
Display Colors 16.7M Colors
Dot Clock 180MHz
Max. Resolution 1920x1080d60Hz
Plug & Play VESA DDCCI/DDC2B
Power consumption
e200cd/m’
ON Mode 20.9W(typ.)
Sleep Mode 0.45W(typ.)
Off Mode 0.35W(typ.)
Input Connector
D-Sub
DVI-D 24pin (Only Dual-Input Model)
DisplayPort 19pin (Only DP Model)
Input Video Signal
Analog:0.7Vp-p(standard), 75 OHM, Positive
Digitaf signal (Only Dual-Input Model)
DP signaUOnly DP Model)
Speakers 2W X 2(Only Audio-Input Model)
Maximum Screen Size
Horizontal:531mm
Vertical:299mm
Power Source 100-240V-, 50/60HZ
Environmental
Considerations
Operating Temp: 5* to 35“C
Storage Temp: -20“ to 60“C
Operating Humidity: 10% to 85%
Dimensions 567.0 (W) X 422.2(H) x 206.8(D)mm
Weight (N. W.) 3.9kg Unit (net)
Mechanism spec
Tilt: -5“ to +25“
Swivel; No
Height adjustment; No
Pivot: No
Detachable foot stand: Yes (by Release button)
External
Controls:
Switch / Buttons
Power Button Auto/ Exit
Left(<)/Right(>) E(Empowering) Key
MENU/ENTER
Functions
Contrast RGB Color temperature
Brightness Language
ACM On\Off OSD position, timeout
Focus Auto configuration (only Analog input model)
Clock Input signal Selection (only Dual input model)
H. Position DDCCI On/Off
V. Position Display information
(Warm) Color Reset
(Cool) Color Exit
* All specifications are subject to change without notice.
Regulatory Compliance
C € @ O F © ® ® ® ®
X f t H O M
