Acer B296CL - Manual (Page 5)

SPECIFICATION
LCD Panel
Driving system TFT Color LCD
Size 29'W(73cm)
Pixel pitch 0.263 mm{H) x 0.263 mm(V)
Brightness 300cd/m^(Typical)
Contrast 100,000,000:1 Max. (ACM)
Viewable angle 178“ (H)178“(V)(CR=10)
Response time 8ms (G to G)
Panel Type IPS
Video Digital Interface
H-Frequency 15KHZ-99KHZ
V-Frequency 23-76HZ
Display Colors 16.7M Colors
Dot Clock 330MHz
Max. Resolution 2560x 1080@60Hz
Plug & Play VESA DDCCI/DDC2B
Power consumption
e200cd/m‘
ON Mode 36.3W(typ.)
Sleep Mode 0.45W(typ.)
Off Mode 0.35W(typ.)
Input Connector
DVI-D 24pin (Only Dual-Input Model)
DisplayPort19pin (Only DP Model)
HDMI 19pin (Only HDMI Model)
USB Hub / USB3.0
X 4 (Only USB Hub Model)
Output Connector DisplayPort19pin (Only DP Model)
Input video Signal
Digital signal (Only Dual-Input Model)
DP signaROnly DP Model)
HDMI signaKonly HDMI-Input Model)
Output Video Signal DisplayPort19pin (Only DP Model)
Speakers 2W X 2(Only Audio-Input Model)
Maximum Screen Size
Horizontal:673mm
Vertical;284mm
Power Source 100-240V-, 50/60HZ
Environmental
Considerations
Operating Temp; 5“ to 35“C
Storage Temp: -20“ to 60“C
Operating Humidity: 10% to 85%
Dimensions 700 (W) X 374~524(H) x 247(D)mm
Weight (N. W.) 8.75kg Unit (net)
Mechanism spec
Tilt:-5“ to +35“
Swivel: Yes
Height adjustment: 150mm
Pivot: Yes
Detachable foot stand: Yes (by Release button)
After rotating, the tilt spec will be 0° to +35°;
swivel spec will be -10° to +10°.
External
Controls:
Switch / Buttons
Power Button PIP
Left(<) /Right(>) E(Empowering) Key
MENU/ENTER
Functions
Contrast RGB Color temperature
Brightness Language
ACM On\Off OSD timeout
6-axis Saturate Input signal Selection (only Dual input model)
6-axis Hue On/Off
DetectVideo Display information
(Warm) Color
(Cool) Color
* All specifications are subject to change without notice.
Regulatory Compliance
^ ^ N214 ^^ ME61 UATRA02 l**«1 -------------------------------------------------------------------------------------------------------------------------------------
