Sears Craftsman 113.177035 - Manual (Page 7)

6. Insert the soft end of the hose, which is
opposite the swivel end, into the vac­
uum port directly above the drain.
7. Place the utility nozzle securely on the
swivel end of the hose and the vac is
ready for use.
NOTE; The swivel end of the hose is
removable if more hoses need to be
attached for more length from the vac. To
remove the swivel portion of the hose,
grasp the hose swivel and firmly pull it out
of the flexible hose. Connect the soft end
of a second hose (accessory #9-17820)
into the swivel end of the original hose by
forcing the sections together until they fit
tightly.
Blowing
Port
Power Cord
Area
Lid
Handle
Dust
Drum
On-Off
Switch
^ Vacuum
^ Port
Variable Speed
Control
Hose
Swivel
End
Larger
Opening
Power
Assembly
Hose
Caster
Utility
Nozzle
Insert the push button end of the “Pos-I-
Lock” hose into the inlet of the vac. The
hose should snap into place. To remove
the hose from the vac, press the release
button in the hose assembly and pull the
hose out of the vac inlet, as shown.
To Store Your Accessories
1. Slide extension handles and accesso­
ries into the slotted areas of the
caster feet for storage.
2. To remove the accessories, rotate and
pull upward.
