Lint Filter and Cover . . .
The iint filter is located at the front
of the dryer in the lower part of the
door opening.
CLEAN THE LINT FILTER AFTER
DRYING EACH LOAD. A clean lint
filter ensures efficient drying and
that clothes remain lint-free when
unloading dryer.
The lint filter on your dryer is
equipped with a cover. This cover
is designed to prevent small
clothing items (baby socks, etc.)
from getting into the lint filter.
The cover sets into the lint filter
and is completely reversible. It is
an optional accessory and can be
removed at any time.
The lint filter has also been
screwed down to prevent clothing
from falling into the air duct. We
recommend that once a year you
remove the two screws and lint
filter and vacuum the area under it.
TO REMOVE THE LINT FILTER:
Remove two screws and lift filter
up and out of door opening. Filter
may be washed if any residue is
noticed on it.
TO REMOVE LINT: Wipe across
the filter with damp fingers.
TO REPLACE LINT FILTER:
Place filter in door recess and
push in firmly. Be sure to replace
the filter with the words facing the
front of the dryer. Replace two
screws.
IMPORTANT: The lint filter must
be in place in the door opening
when using dryer or loading and
unloading dryer. If the filter is not in
place, clothing could fall into the
front air duct and get into the
exhaust system, causing damage
to the motor.
UNT FILTER
COVER
DOOR
UNER
LINT
FILTER
D244IE3C
Door Liner..
Lint can accumulate in the door
liner (opening in bottom of dryer
door).
Occasionally open dryer door and
vacuum the door liner.
50327«
15
