Programming Occupied and Unoccupied
Periods

Select Occupied 1 to run
on this day (On), or not to
run this day (Off).

Off

Select Yes or No to copy
the previous day's

/ program to this day.

Mil

I I L I

W e

LIJ

p’i

Advanced Setup

Press ihe Mode button.

J While holding the Mode,

press the Override button

for 10 seconds io enter

Setup screens.

Adjust the time of day
clock.

Tip: To change hours quickly, press and

hold the override button in and press
the up Or down huttons.

Select the day of the
week.

NOTE: Each step number is located at

the top right corner of the dislay
for easy reference.

imr

Selecting Yes, then pressing mode wiH copy the previous day's program
and then will ask the same copy question again. If yes Is selected each
time, this routine will repeat untii Saturday is copied to Sunday. After Satur
day is copied to Sunday, the copy command is unavailable.

If no is selected, as in previous steps, flashing prompts for input will appear

for start and stop times for Occupied 1. If more than one occupied period
was selected in Step 1 on page 3, then cool/heat set points, and start/stop
times for additional occupied periods will be prompted.

Setect fan operation,
Fan III or Fan Auto.

= Low Speed Fan

■ I

= Medium Speed Fan

i l l = High Speed Fan

PROGRAMMING NOTES

• If only one Occupied period is selected in Step 1 on

page 3, Occupied 2 and 3 programming steps are
skipped. Further, if only 2 occupied periods are
selected, Occupied 3 programming steps are
skipped.

• Heat and Cool set points for Occupied 1 are the

same for every day of the week. Heat and Cool set
points for Occupied 2 and 3 can be adjusted differ
ently for weekdays and weekends, if desired.

• If

the start time Is set later In the day than the

stop time, the program will run from the start time
to midnight and from midnight to the stop time on
the same day. For example: 9:00pm start, 8:00am
stop, on Monday. In this example the program will

run from 12:00am Monday to 8:00am Monday and

again from 9:00pm Monday to 12:00pm Monday.

• The Unoccupied settings take effect at all times

when: (1) the program is on and (2) the current time

is outside a preset occupied period. For this reason
start and stop times are not necessary for
unoccupied.

• If the same start and stop times are programmed in

for an occupied period, then it will run 24 hours.

• If one occupied period starts and stops within

another occupied period the lower occupied num
ber has priority. For example: If Occupied 3 is pro
grammed to be “on” 24 hours, and Occupied 2 is
programmed to run that day, then Occupied 2 set

tings will take over from Occupied 3 between
Occupied 2 start and stop times.

Select Heat Pump, On or Off.

Adjust the deadband
from 1 to 6 degrees F.

AdjusUhe

minimum

difference

between

cooling and heating
set points.

(0° to 6 F)

Adjust the maximum
allowable heal set point
when security is in etlect.
(Step 8 only appears

if Step 9 is not 0.)

(35 to 99 F)

Select the cycles per
hour limit.

d=cycles per hour
iimil defeated.
di =d -t- defeat 5 min.

Compressor lockout,

(d, d1,

2 -

Sff

Select the security level:
0=no security in effect
1 =set point range limited
2=1 + program on all times

3=2 -

1- prohibits set point

changes

0 f'f

Cf U
